Parameter Descriptions
3.10 Parameters: 8-** Communications and
Options
3.10.1 8-0* General Settings
3 3

8-01 Control Site

Option:
[0] Digital and
*
ctrl.word
[1] Digital only
[2] Controlword only

8-02 Control Word Source

Select the source of the control word: one of two serial interfaces
or four installed options. During initial power-up, the Adjustable
frequency drive automatically sets this parameter to Option A [3]
if it detects a valid Serial communication bus option installed in
slot A. If the option is removed, the Adjustable frequency drive
detects a change in the configuration, sets 8-02 Control Word
Source back to default setting RS-485, and the Adjustable
frequency drive then trips. If an option is installed after initial
power-up, the setting of 8-02 Control Word Source will not
change but the Adjustable frequency drive will trip and display:
Alarm 67 Option Changed.
When you retrofit a bus option into a Adjustable frequency drive
that did not have a bus option installed to begin with, you must
take an ACTIVE decision to move the control to bus-based. This
is done for safety reasons in order to avoid an accidental change.
Option:
[0]
[1]
[2]
[3]
*
[4]
[5]
[6]
[30]
NOTE!
This parameter cannot be adjusted while the motor is
running.
8-03 Control Word Timeout Time
Range:
1.0 s [Application
*
dependant]
3-84
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20872-Danfoss-131H4490-VLT-Automation-VT-Drive-VFD-FC302-460V-25-HP.aspx
FC 300 Programming Guide
Function:
The setting in this parameter overrides
the settings in 8-50 Coasting Select to
8-56 Preset Reference Select.
Control by using both digital input and
control word.
Control by using digital inputs only.
Control by using control word only.
Function:
None
FC RS485
FC USB
Option A
Option B
Option C0
Option C1
External Can
Function:
Enter the maximum time expected to
pass between the reception of two
consecutive messages. If this time is
exceeded, it indicates that the serial
MG33MD22 - VLT
8-03 Control Word Timeout Time
Range:

8-04 Control Word Timeout Function

Select the timeout function. The timeout function activates when
the control word fails to be updated within the time period
specified in 8-03 Control Word Timeout Time.
Option:
[0] Off Resumes control via serial bus (Serial
*
communication bus or standard) using the
most recent control word.
[1] Freeze output Freezes output frequency until communi-
cation resumes.
[2] Stop Stops with auto-restart when communi-
cation resumes.
[3] Jogging Runs the motor at JOG frequency until
communication resumes.
[4] Max. speed Runs the motor at maximum frequency
until communication resumes.
[5] Stop and trip Stops the motor, then resets the Adjustable
frequency drive in order to restart: via the
Serial communication bus, via the reset
button on the LCP or via a digital input.
[7] Select setup 1 Changes the set-up upon reestablishment of
communication following a control word
timeout. If communication resumes causing
the timeout situation to disappear,
8-05 End-of-Timeout Function defines
whether to resume the set-up used before
the timeout or to retain the set-up
endorsed by the timeout function.
[8] Select setup 2 See [7] Select setup 1
[9] Select setup 3 See [7] Select setup 1
[10] Select setup 4 See [7] Select setup 1
[26] Trip
NOTE!
The following configuration is required in order to change
the set-up after a timeout:
Set 0-10 Active Set-up to [9] Multi set-up and select the
relevant link in 0-12 This Set-up Linked to.
®
