Parameter Descriptions
5-60 Terminal 27 Pulse Output Variable
Option:
[106] Power
3 3
[107] Speed
[108] Torque
[109] Max Out Freq
[119] Torque % lim

5-62 Pulse Output Max Freq #27

Range:
Application
dependent
*
5000. Hz
*

5-63 Terminal 29 Pulse Output Variable

Option:
[0] No operation
*
[45] Bus ctrl.
[48] Bus ctrl., timeout
[51] MCO controlled
[100] Output frequency
[101] Reference
[102] Feedback
[103] Motor current
[104] Torque rel to limit
[105] Torq relate to rated
[106] Power
[107] Speed
[108] Torque
[109] Max Out Freq
[119] Torque % lim
5-65 Pulse Output Max Freq #29
Set the maximum frequency for terminal 29 corresponding to the
output variable set in 5-63 Terminal 29 Pulse Output Variable.
Range:
5000 Hz
*
3-66
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20872-Danfoss-131H4490-VLT-Automation-VT-Drive-VFD-FC302-460V-25-HP.aspx
FC 300 Programming Guide
Function:
Function:
[0 - 32000 Set the maximum frequency for
Hz] terminal 27, corresponding to the
output variable selected in
5-60 Terminal 27 Pulse Output
Variable.
[0 - 32000 Set the maximum frequency for
Hz] terminal 27, corresponding to the
output variable selected in
5-60 Terminal 27 Pulse Output
Variable.
Function:
Select the desired display output for
terminal 29. This parameter is
available for FC 302 only.
Function:
[0 - 32000 Hz]
MG33MD22 - VLT

5-66 Terminal X30/6 Pulse Output Variable

Select the variable for read-out on terminal X30/6.
This parameter is active when option module MCB 101 is
installed in the Adjustable frequency drive.
Same options and functions as parameter group 5-6*.
Option:
[0] No operation
*
[45] Bus ctrl.
[48] Bus ctrl., timeout
[51] MCO controlled
[100] Output frequency
[101] Reference
[102] Feedback
[103] Motor current
[104] Torque rel to limit
[105] Torq relate to rated
[106] Power
[107] Speed
[108] Torque
[109] Max Out Freq
[119] Torque % lim
5-68 Pulse Output Max Freq #X30/6
Select the maximum frequency on terminal X30/6 referring to
the output variable in 5-66 Terminal X30/6 Pulse Output Variable.
This parameter cannot be adjusted while the motor is running.
This parameter is active when option module MCB 101 is
mounted in the Adjustable frequency drive.
Range:
Application
dependent
*

3.7.7 5-7* 24 V Encoder Input

Connect the 24 V encoder to terminal 12 (24V DC supply),
terminal 32 (Channel A), terminal 33 (Channel B), and
terminal 20 (GND). The digital inputs 32/33 are active for
encoder inputs when 24V encoder is selected in 1-02 Flux
Motor Feedback Source and 7-00 Speed PID Feedback Source.
The encoder used is a dual channel (A and B) 24V type.
Max input frequency: 110kHz.
Encoder Connection to the Adjustable frequency drive
24V incremental encoder. Max. cable length 16 ft [5 m].
®
is a registered Danfoss trademark
Function:
Function:
[0 - 32000 Hz]
