7-12 Torque PI Proportional Gain
Range: Function:
100 % [0 - 500 %] Enter the proportional gain value for the
*
torque controller. Selection of a high value
makes the controller react faster. Too high
a setting leads to controller instability.
7-13 Torque PI Integration Time
Range: Function:
0.020 s [0.002 - 2.000 Enter the integration time for the
*
s] torque controller. Selecting a low value
causes the controller to react faster.
Too low a setting leads to control
instability.

3.9.3 7-2* Process Ctrl. Feedb.

Select the feedback sources for the process PID control,
and the way in which this feedback should be handled.
7-20 Process CL Feedback 1 Resource
Option:
[0] No function
*
[1] Analog input 53
[2] Analog input 54
[3] Frequency input 29
[4] Frequency input 33
[7] Analog input X30/11
[8] Analog input X30/12
[15] Analog Input X48/2
7-22 Process CL Feedback 2 Resource
Option:
[0] No function
*
[1] Analog input 53
[2] Analog input 54
