Parameter Descriptions

30-81 Brake Resistor (ohm)

Range:
Application [Application
dependent dependant]
*
30-83 Speed PID Proportional Gain
Range:
Application [0.0000 -
dependent 1.0000 ]
*
Application [0.0000 -
dependent 1.0000 ]
*

30-84 Process PID Proportional Gain

Range: Function:
0.100 [0.000 - Enter the process controller propor-
*
10.000 ] tional gain. Quick control is obtained at
high amplification. However, if the
amplification is too great, the process
may become unstable.
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20872-Danfoss-131H4490-VLT-Automation-VT-Drive-VFD-FC302-460V-25-HP.aspx
FC 300 Programming Guide
Function:
Set the brake resistor value in
Ohms. This value is used for
monitoring the power to the
brake resistor in 2-13 Brake
Power Monitoring. This
parameter is only active in
drives with an integral dynamic
brake.
Function:
Enter the speed controller
proportional gain. Quick control
is obtained at high amplification.
However, if the amplification is
too great, the process may
become unstable.
Enter the speed controller
proportional gain. Quick control
is obtained at high amplification.
However, if the amplification is
too great, the process may
become unstable.
®
MG33MD22 - VLT is a registered Danfoss trademark
3 3
3-153
