Parameter Descriptions
NOTE!
When Auto Reset/Warning is selected the Adjustable
frequency drive opens up for automatic restart.
3 3
Overview of functions, alarms and warnings
Function
No Function
Safe Stop Alarm
Safe Stop Warning
PTC 1 Alarm
PTC 1 Warning
PTC 1 & Relay A
PTC 1 & Relay W
PTC 1 & Relay A/W
PTC 1 & Relay W/A
W means warning, and A means alarm. For further information, see
Alarms and Warnings in section Troubleshooting in the Design Guide
or in the Instruction Manual.
A dangerous failure related to the safe stop will give alarm:
Dangerous Failure [A72].
Please refer to in .
5-20 Terminal X46/1 Digital Input
Option:
[0] No operation This parameter is active when option module
*
5-21 Terminal X46/3 Digital Input
Option:
[0] No operation This parameter is active when option
*
5-22 Terminal X46/5 Digital Input
Option:
[0] No operation This parameter is active when option
*
3-54
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20872-Danfoss-131H4490-VLT-Automation-VT-Drive-VFD-FC302-460V-25-HP.aspx
FC 300 Programming Guide
No. PTC Relay
[0] - -
[1]* - Safe Stop [A68]
[3] - Safe Stop [W68]
[4] PTC 1 Safe Stop -
[A71]
[5] PTC 1 Safe Stop -
[W71]
[6] PTC 1 Safe Stop Safe Stop [A68]
[A71]
[7] PTC 1 Safe Stop Safe Stop [W68]
[W71]
[8] PTC 1 Safe Stop Safe Stop [W68]
[A71]
[9] PTC 1 Safe Stop Safe Stop [A68]
[W71]
Function:
MCB 113 is installed in the Adjustable
frequency drive. Functions are described
under 5-1* Digital Inputs
Function:
moduleMCB 113 is installed in the Adjustable
frequency drive. Functions are described
under 5-1* Digital Inputs
Function:
moduleMCB 113 is installed in the Adjustable
frequency drive. Functions are described
under 5-1* Digital Inputs
MG33MD22 - VLT
5-23 Terminal X46/7 Digital Input
Option: Function:
[0] No operation This parameter is active when option
*
moduleMCB 113 is installed in the Adjustable
frequency drive. Functions are described
under 5-1* Digital Inputs
5-24 Terminal X46/9 Digital Input
Option: Function:
[0] No operation This parameter is active when option module
*
MCB 113 is installed in the Adjustable
frequency drive. Functions are described
under 5-1* Digital Inputs
5-25 Terminal X46/11 Digital Input
Option: Function:
[0] No operation This parameter is active when option
*
moduleMCB 113 is installed in the Adjustable
frequency drive. Functions are described
under 5-1* Digital Inputs
5-26 Terminal X46/13 Digital Input
Option: Function:
[0] No operation This parameter is active when option module
*
MCB 113 is installed in the Adjustable
frequency drive. Functions are described
under 5-1* Digital Inputs

3.7.3 5-3* Digital Outputs

The 2 solid-state digital outputs are common for terminals
27 and 29. Set the I/O function for terminal 27 in
5-01 Terminal 27 Mode, and set the I/O function for
terminal 29 in 5-02 Terminal 29 Mode.
NOTE!
These parameters cannot be adjusted while the motor is
running.
[0] No operation
[1] Control ready
[2] Drive ready
[3] Drive ready /
remote control
®
is a registered Danfoss trademark
Default for all digital outputs and relay
outputs
The control card is ready. For example,
Feedback from a Adjustable frequency
drive where the control is supplied by an
external 24 V (MCB 107) and the main
power to the unit is not detected.
The Adjustable frequency drive is ready
for operation and applies a supply signal
on the control board.
The Adjustable frequency drive is ready
for operation and is in [Auto on] mode.
