Danfoss VLT AutomationDrive Programming Manual page 215

Parameter Lists
Par. Parameter description
No.
#
33-54 Terminal X57/5 Digital Input
33-55 Terminal X57/6 Digital Input
33-56 Terminal X57/7 Digital Input
33-57 Terminal X57/8 Digital Input
4 4
33-58 Terminal X57/9 Digital Input
33-59 Terminal X57/10 Digital Input
33-60 Terminal X59/1 and X59/2 Mode
33-61 Terminal X59/1 Digital Input
33-62 Terminal X59/2 Digital Input
33-63 Terminal X59/1 Digital Output
33-64 Terminal X59/2 Digital Output
33-65 Terminal X59/3 Digital Output
33-66 Terminal X59/4 Digital Output
33-67 Terminal X59/5 Digital Output
33-68 Terminal X59/6 Digital Output
33-69 Terminal X59/7 Digital Output
33-70 Terminal X59/8 Digital Output
33-8* Global Parameters
33-80 Activated Program Number
33-81 Power-up State
33-82 Drive Status Monitoring
33-83 Behavior After Error
33-84 Behavior afterEsc.
33-85 MCO Supplied by External 24VDC
33-86 Terminal at alarm
33-87 Terminal state at alarm
33-88 Status word at alarm
33-9* MCO Port Settings
33-90 X62 MCO CAN node ID
33-91 X62 MCO CAN baud rate
33-94 X60 MCO RS485 serial termination
33-95 X60 MCO RS485 serial baud rate
4-34
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20872-Danfoss-131H4490-VLT-Automation-VT-Drive-VFD-FC302-460V-25-HP.aspx
FC 300 Programming Guide
Default value
[0] No function
[0] No function
[0] No function
[0] No function
[0] No function
[0] No function
[1] Output
[0] No function
[0] No function
[0] No function
[0] No function
[0] No function
[0] No function
[0] No function
[0] No function
[0] No function
[0] No function
-1 N/A
[1] Motor ON
[1] On
[0] Coast
[0] Controlled stop
[0] No
[0] Relay 1
[0] Do nothing
0 N/A
127 N/A
[20] 125 Kbps
[0] Off
[2] 9600 Baud
®
MG33MD22 - VLT is a registered Danfoss trademark
4-set-up FC 302 Change
only during
operation
2 set-ups TRUE
2 set-ups TRUE
2 set-ups TRUE
2 set-ups TRUE
2 set-ups TRUE
2 set-ups TRUE
2 set-ups FALSE
2 set-ups TRUE
2 set-ups TRUE
2 set-ups TRUE
2 set-ups TRUE
2 set-ups TRUE
2 set-ups TRUE
2 set-ups TRUE
2 set-ups TRUE
2 set-ups TRUE
2 set-ups TRUE
2 set-ups TRUE
2 set-ups TRUE
2 set-ups TRUE
2 set-ups TRUE
2 set-ups TRUE
2 set-ups TRUE
2 set-ups TRUE
2 set-ups TRUE
2 set-ups TRUE
2 set-ups TRUE
2 set-ups TRUE
2 set-ups TRUE
2 set-ups TRUE
Conver- Type
sion
index
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
0 Int8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
0 Uint16
0 Uint8
- Uint8
- Uint8
- Uint8
