Parameter Descriptions

3.13 Parameters: 12-** Ethernet

3.13.1 12-0* IP Settings

12-00 IP Address Assignment
Option: Function:
Selects the IP address assignment method.
[0] Manual IP-address can be set in12-01 IP Address IP Address.
*
[1] DHCP The IP address is assigned via DHCP server.
[2] BOOTP The IP address is assigned via BOOTP server.
12-01 IP Address
Range:
[000.000.000.000–
255.255.255.255]
12-02 Subnet Mask
Range:
[000.000.000.000–
255.255.255.255]
12-03 Default Gateway
Range:
[000.000.000.000 –
255.255.255.255]
12-04 DHCP Server
Range:
[000.000.000.000–
255.255.255.255]
NOTE!
A power cycle is necessary after setting the IP parameters
manually.
12-05 Lease Expires
Range: Function:
[dd:hh:mm:ss] Read only. Displays the lease time left for the
current DHCP-assigned IP address.
12-06 Name Servers
Option: Function:
IP addresses of Domain Name Servers. Can
be automatically assigned when using DHCP.
[0] Primary DNS
[1] Secondary DNS
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20872-Danfoss-131H4490-VLT-Automation-VT-Drive-VFD-FC302-460V-25-HP.aspx
FC 300 Programming Guide
Function:
Configure the IP address of the
option. Read-only if 12-00 IP Address
Assignment set to DHCP or BOOTP.
Function:
Configure the IP subnet mask of the
option. Read-only if 12-00 IP Address
Assignment set to DHCP or BOOTP.
Function:
Configure the IP default gateway of
the option. Read-only if 12-00 IP
Address Assignment set to DHCP or
BOOTP.
Function:
Read only. Displays the IP address
of the found DHCP or BOOTP
server.
®
MG33MD22 - VLT is a registered Danfoss trademark
12-07 Domain Name
Range: Function:
Blank [0–19 characters] Domain name of the attached
network. Can be automatically
assigned when using DHCP.
12-08 Host Name
Range: Function:
Blank [0–19 characters] Logical (given) name of option.
12-09 Physical Address
Range:
[00:1B:08:00:00:00–00:1B: Read only: Displays the Physical
08:FF:FF:FF] (MAC) address of the option.

3.13.2 12-1* Ethernet Link Parameters

12-1* Ethernet link parameters
Option: Function:
Applies for whole parameter group.
[0] Port 1
[1] Port 2
12-10 Link Status
Option: Function:
Read only. Displays the link status of the Ethernet
ports.
[0] No link
[1] Link
12-11 Link Duration
Option: Function:
Link Duration Port 1 Read only. Displays the duration of
(dd:hh:mm:ss) the present link on each port in
dd:hh:mm:ss.

12-12 Auto Negotiation

Option: Function:
Configures Auto Negotiation of Ethernet link
parameters, for each port: ON or OFF.
[0] Off Link Speed and Link Duplex can be configured in
12-13 Link Speed and 12-14 Link Duplex.
[1] On

12-13 Link Speed

Option: Function:
Forces the link speed for each port at 10 or 100
Mbps. If 12-12 Auto Negotiation is set to: ON,
this parameter is read only and displays the
actual link speed. "None" is displayed if no link
is present.
[0] None
*
[1] 10 Mbps
Function:
