Parameter Lists
1-10 Motor Construction
1-01 Motor Control Principle
1-50 Motor Magnetisation at Zero
Speed
1-51 Min Speed Normal
Magnetising [RPM](Par. 002 = rmp)
1-52 Min Speed Normal Magnetising
[Hz](Par. 002 = Hz)
1-53 Model Shift Frequency
1-54 Voltage reduction in
fieldweakening
1-55 U/f Characteristic - U
1-56 U/f Characteristic - F
1-58 Flystart Test Pulses Current
1-59 Flystart Test Pulses Frequency
1-60 Low Speed Load Compensation
1-61 High Speed Load Compen-
sation
1-62 Slip Compensation
1-63 Slip Compensation Time
Constant
1-64 Resonance Dampening
1-65 Resonance Dampening Time
Constant
1-66 Min. Current at Low Speed
1-67 Load Type
1-68 Minimum Inertia
1-69 Maximum Inertia
1-71 Start Delay
1-72 Start Function
1-73 Flying Start
1-74 Start Speed [RPM](Par. 002 =
rmp)
1-75 Start Speed [Hz](Par. 002 = Hz)
1-76 Start Current
6) Used when 1-03 Torque Characteristics is constant power
7) Not used when 1-03 Torque Characteristics = VT
8) Part of resonance damping
