Parameter Descriptions
13-01 Start Event
Option:
[42] Auto-reset Trip
3 3
[43] Ok key
[44] Reset key
[45] Left key
[46] Right key
[47] Up key
[48] Down key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[94] RS Flipflop 0
[95] RS Flipflop 1
[96] RS Flipflop 2
[97] RS Flipflop 3
[98] RS Flipflop 4
[99] RS Flipflop 5
[100] RS Flipflop 6
[101] RS Flipflop 7

13-02 Stop Event

Select the Boolean (TRUE or FALSE) input to activate Smart Logic
Control.
Option:
[0] False
*
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current limit
[7] Out of current range
[8] Below I low
[9] Above I high
[10] Out of speed range
[11] Below speed low
[12] Above speed high
[13] Out of feedb. range
3-112
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20872-Danfoss-131H4490-VLT-Automation-VT-Drive-VFD-FC302-460V-25-HP.aspx
FC 300 Programming Guide
Function:
Auto-reset Trip [42]: an auto reset is
performed.
OK key [43] The [OK] key is pressed.
Reset key [44] The [Reset] key is
pressed.
Left key [45] The [◄] key is pressed.
Right key [46] The[►] key is pressed.
▲
Up key [47] The [ ] key is pressed.
▼
Down key [48] The [ ] key is pressed.
Comparator 4 [50] Use the result of
comparator 4.
Comparator 5 [51] Use the result of
comparator 5.
Logic rule 4 [60] Use the result of logic
rule 4.
Logic rule 5 [61] Use the result of logic
rule 5.
Function:
For descriptions [0] - [61], see
13-01 Start Event Start Event
MG33MD22 - VLT
13-02 Stop Event
Select the Boolean (TRUE or FALSE) input to activate Smart Logic
Control.
Option:
[14] Below feedb. low
[15] Above feedb. high
[16] Thermal warning
[17] Mains out of range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[37] Digital input DI32
[38] Digital input DI33
[39] Start command
[40] Drive stopped
[41] Reset Trip
[42] Auto-reset Trip
[43] Ok key
[44] Reset key
[45] Left key
[46] Right key
[47] Up key
[48] Down key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
®
is a registered Danfoss trademark
Function:
SL Timeout 3 [70] Smart Logic
Controller timer 3 is timed out.
SL Timeout 4 [71] Smart Logic
Controller timer 4 is timed out.
SL Timeout 5 [72] Smart Logic
Controller timer 5 is timed out.
