Parameter Descriptions
Feedback
Disturbed feedback signal
3 3
Feedback
Filtered feedback signal
7-07 Speed PID Feedback Gear Ratio
Range:
1.0000 [Application dependant]
*
3-80
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20872-Danfoss-131H4490-VLT-Automation-VT-Drive-VFD-FC302-460V-25-HP.aspx
0.6
Lowpass lter
f = 10 Hz
g
0.6
MG33MD22 - VLT
FC 300 Programming Guide

7-08 Speed PID Feed Forward Factor

Range:
0 %
*
t (Sec.)

7-09 Speed PID Error Correction w/ Ramp

Range:
300 RPM
Motor
Speed
Motor
Speed
t (Sec.)
Function:
Ramp

3.9.2 7-1* Torque PI Control

Parameters for configuring the torque PI control in torque
open-loop (1-00 Configuration Mode).
®
is a registered Danfoss trademark
Motor
Par 7-07=1.00
Function:
[0 - 500 %] The reference signal bypasses the speed
controller by the amount specified. This
feature increases the dynamic performance
of the speed control loop.
Function:
[10 - 100000 The speed error between ramp and
*
RPM] actual speed is held up against the
setting in this parameter. If the speed
error exceeds this parameter entry,
the speed error will be corrected via
ramping in a controlled way.
7-09
Torque
Time
Limit
7-09
Torque
Limit
Time
Motor Speed
n1 n2
Par 7-07=n1/n2
