Introduction

1 Introduction
Programming Guide
Software version: 6.5x
This Programming Guide can be used for all FC 300 adjustable
frequency drives with software version 6.5x.
The software version number can be seen from 15-43 Software
Version.

1.1.1 Approvals

1.1.2 Symbols

Symbols used in this guide.
NOTE!
Indicates something to be noted by the reader.
CAUTION
Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury or
equipment damage.
WARNING
Indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
* Indicates default setting
