Parameter Descriptions
13-52 SL Controller Action
Array [20]
Option: Function:
[2] Select set-up Select set-up 1 [2] - changes the active set-
1 up (0-10 Active Set-up) to '1'.
If the set-up is changed, it will merge with
other set-up commands coming from either
the digital inputs or via a serial communi-
cation bus.
[3] Select set-up Select set-up 2 [3] - changes the active set-
2 up 0-10 Active Set-up) to '2'.
If the set-up is changed, it will merge with
other set-up commands coming from either
the digital inputs or via a serial communi-
cation bus.
[4] Select set-up Select set-up 3 [4] - changes the active set-
3 up (0-10 Active Set-up) to '3'.
If the set-up is changed, it will merge with
other set-up commands coming from either
the digital inputs or via a serial communi-
cation bus.
[5] Select set-up Select set-up 4 [5] - changes the active set-
4 up (0-10 Active Set-up) to '4'.
If the set-up is changed, it will merge with
other set-up commands coming from either
the digital inputs or via a serial communi-
cation bus.
[10] Select preset Select preset reference 0 [10] – selects preset
ref 0 reference 0.
If the active preset reference is changed, it
will merge with other preset reference
commands coming from either the digital
inputs or via a serial communication bus.
[11] Select preset Select preset reference 1 [11] – selects preset
ref 1 reference 1.
If the active preset reference is changed, it
will merge with other preset reference
commands coming from either the digital
inputs or via a serial communication bus.
[12] Select preset Select preset reference 2 [12] – selects preset
ref 2 reference 2.
If the active preset reference is changed, it
will merge with other preset reference
commands coming from either the digital
inputs or via a serial communication bus.
[13] Select preset Select preset reference 3 [13] – selects preset
ref 3 reference 3.
If the active preset reference is changed, it
will merge with other preset reference
commands coming from either the digital
inputs or via a serial communication bus.
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20872-Danfoss-131H4490-VLT-Automation-VT-Drive-VFD-FC302-460V-25-HP.aspx
FC 300 Programming Guide
[14] Select preset
[15] Select preset
[16] Select preset
[17] Select preset
[18] Select ramp 1
[19] Select ramp 2
[20] Select ramp 3
[21] Select ramp 4
[22] Run
[23] Run reverse
[24] Stop
[25] Qstop
[26] Dcstop
[27] Coast
[28] Freeze output
®
MG33MD22 - VLT is a registered Danfoss trademark
13-52 SL Controller Action
Array [20]
Option: Function:
Select preset reference 4 [14] – selects preset
ref 4 reference 4.
If the active preset reference is changed, it
will merge with other preset reference
commands coming from either the digital
inputs or via a serial communication bus.
Select preset reference 5 [15] – selects preset
ref 5 reference 5.
If the active preset reference is changed, it
will merge with other preset reference
commands coming from either the digital
inputs or via a serial communication bus.
Select preset reference 6 [16] – selects preset
ref 6 reference 6.
If the active preset reference is changed, it
will merge with other preset reference
commands coming from either the digital
inputs or via a serial communication bus.
Select preset reference 7 [17] - selects preset
ref 7 reference 7.
If the active preset reference is changed, it
will merge with other preset reference
commands coming from either the digital
inputs or via a serial communication bus.
Select ramp 1 [18] - selects ramp 1.
Select ramp 2 [19] - selects ramp 2.
Select ramp 3 [20] - selects ramp 3.
Select ramp 4 [21] - selects ramp 4.
Run [22] - issues a start command to the
Adjustable frequency drive.
Run reverse [23] - issues a start reverse
command to the Adjustable frequency
drive.
Stop [24] - issues a stop command to the
Adjustable frequency drive.
Q stop [25] - issues a quick stop command
to the Adjustable frequency drive.
Dcstop [26] - issues a DC stop command to
the Adjustable frequency drive.
Coast [27] - the Adjustable frequency drive
coasts immediately. All stop commands
including the coast command stop the SLC.
Freeze output [28] - freezes the output
frequency of the Adjustable frequency
drive.
3 3
