Parameter Descriptions

12-96 Port Config

Enables/disables port mirroring function. For troubleshooting
with a network analyzer tool.
Option:
[2] Mirror Port 2 to 1
[254] Mirror Int. Port to 1
[255] Mirror Int. Port to 2

12-98 Interface Counters

Option:
[0] In Octets
[1] In Unicast Packets
[2] In Non-Unicast Packets
[3] In Discards
[4] In Errors
[5] In Unknown Protocols
[6] Out Octets
[7] Out Unicast Packets
[8] Out Non-Unicast Packets
[9] Out Discards
[10] Out Errors

12-99 Media Counters

Option:
Read only. Advanced interface
counters from the built-in switch can
be used for low-level troubleshooting.
The parameter shows the sum of port
1 + port 2.
[0] Alignment Errors
[1] FCS Errors
[2] Single Collisions
[3] Multiple Collisions
[4] SQE Test Errors
[5] Deferred Errors
[6] Late Collisions
[7] Excessive Collisions
[8] MAC Transmit Errors
[9] Carrier Sense Errors
[10] Frame Too Long
[11] MAC Receive Errors
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20872-Danfoss-131H4490-VLT-Automation-VT-Drive-VFD-FC302-460V-25-HP.aspx
FC 300 Programming Guide
Function:
All network traffic on port 2 will
be mirrored to port 1.
Function:
Read only. Advanced interface
counters from the built-in switch
can be used for low-level trouble-
shooting. The parameter shows
the sum of port 1 + port 2.
Function:
®
