Parameter Descriptions
6-60 Terminal X30/8 Output
Option:
3 3
[0] No
*
operation
[52] MCO
0-20mA
[100] Output
frequency
[101] Reference
[102] Feedback
[103] Motor
current
[104] Torque rel
to limit
[105] Torq relate
to rated
[106] Power
[107] Speed
[108] Torque
[109] Max Out
Freq
[113] PID
Clamped
Output
[119] Torque %
lim
[130] Output
freq.
4-20mA
3-74
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20872-Danfoss-131H4490-VLT-Automation-VT-Drive-VFD-FC302-460V-25-HP.aspx
FC 300 Programming Guide
Function:
read out in LCP in 16-65 Analog Output 42
[mA].
When no signal on the analog output.
0hz = 0mA; 100hz = 20mA.
3-00 Reference Range [Min - Max] 0% = 0mA;
100% = 20mA
3-00 Reference Range [-Max - Max] -100% =
0mA; 0% = 10mA; +100% = 20 mA
Value is taken from 16-37 Inv. Max. Current.
Inverter max. current (160% current) is equal
to 20mA.
Example: Inverter norm current (15 hp [11
kW]) = 24 A. 160% = 38.4 A. Motor norm
current = 22 A Readout 11.46mA.
mA x 22 A
20
mA
= 11.46
A
38.4
If the norm motor current is equal to 20mA,
the output setting of 6-62 Terminal X30/8
Max. Scale is:
I VLT x 100
Max x 100
38.4
= = 175 %
I Motor
22
Norm
The torque setting is related to setting in
4-16 Torque Limit Motor Mode.
The torque is related to the motor torque
setting.
Taken from 1-20 Motor Power [kW].
Taken from 3-03 Maximum Reference. 20mA =
value in 3-03 Maximum Reference
Torque reference related to 160% torque.
In relation to 4-19 Max Output Frequency.
0hz = 4mA, 100hz = 20mA
MG33MD22 - VLT
6-60 Terminal X30/8 Output
Option: Function:
[131] Reference 3-00 Reference Range [Min-Max] 0% = 4mA;
4-20mA 100% = 20mA
3-00 Reference Range [-Max-Max] -100% =
4mA; 0% = 12 mA; +100% = 20 mA
[132] Feedback
4-20mA
[133] Motor cur. Value is taken from 16-37 Inv. Max. Current.
4-20mA Inverter max. current (160% current) is equal
to 20mA.
Example: Inverter norm current (15 hp [11
kW]) = 24 A. 160% = 38.4 A. Motor norm
current = 22 A Readout 11.46mA.
16
If the norm motor current is equal to 20mA,
the output setting of 6-62 Terminal X30/8
Max. Scale is:
I VLT
[134] Torq.% lim The torque setting is related to setting in
4-20 mA 4-16 Torque Limit Motor Mode.
[135] Torq.% The torque setting is related to the motor
nom 4-20 torque setting.
mA
[136] Power Taken from 1-20 Motor Power [kW]
4-20mA
[137] Speed Taken from 3-03 Maximum Reference. 20mA =
4-20mA Value in 3-03 Maximum Reference.
[138] Torque Torque reference related to 160% torque.
4-20mA
[139] Bus ctrl. An output value set from serial communi-
0-20 mA cation bus process data. The output will work
independently of internal functions in the
Adjustable frequency drive.
[140] Bus ctrl. An output value set from serial communi-
4-20 mA cation bus process data. The output will work
independently of internal functions in the
Adjustable frequency drive.
[141] Bus ctrl 4-54 Warning Reference Low defines the
0-20mA t.o. behavior of the analog output in case of bus
timeout.
[142] Bus ctrl 4-54 Warning Reference Low defines the
4-20mA t.o. behavior of the analog output in case of bus
timeout.
[149] Torque % Torque% Lim 4-20mA: Torque reference.
lim 4-20mA 3-00 Reference Range [Min-Max] 0% = 4mA;
100% = 20mA
®
is a registered Danfoss trademark
mA x 22 A
= 9.17 mA
38.4 A
x 100
Max x 100
38.4
= = 175 %
I Motor 22
Norm
