Parameter Descriptions
5-14 Terminal 32 Digital Input
Option: Function:
Select the function from the available digital
input range and the additional options [60],
[61], [63] and [64]. Counters are used in
Smart Logic Control functions.
[0] No operation Functions are described under 5-1* Digital
*
Inputs
5-15 Terminal 33 Digital Input
Option: Function:
Select the function from the available digital
input range and the additional options [60],
[61], [63] and [64]. Counters are used in
Smart Logic Control functions.
[0] No operation Functions are described under 5-1* Digital
*
Inputs
5-16 Terminal X30/2 Digital Input
Option: Function:
[0] No operation This parameter is active when option module
*
MCB101 is installed in the Adjustable
frequency drive. Functions are described
under 5-1* Digital Inputs
5-17 Terminal X30/3 Digital Input
Option: Function:
[0] No operation This parameter is active when option module
*
MCB101 is installed in the Adjustable
frequency drive. Functions are described
under 5-1* Digital Inputs
5-18 Terminal X30/4 Digital Input
Option: Function:
[0] No operation This parameter is active when option module
*
MCB101 is installed in the Adjustable
frequency drive. Functions are described
under 5-1* Digital Inputs

5-19 Terminal 37 Safe Stop

Option: Function:
[1] Safe Stop Coasts Adjustable frequency drive when safe
Alarm stop is activated. Manual reset from LCP,
*
digital input or serial communication bus.
[3] Safe Stop Coasts Adjustable frequency drive when safe
Warning stop is activated (T-37 off). When safe stop
circuit is reestablished, the Adjustable
frequency drive will continue without manual
reset.
[4] PTC 1 Alarm Coasts Adjustable frequency drive when safe
stop is activated. Manual reset from LCP,
digital input or serial communication bus.
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20872-Danfoss-131H4490-VLT-Automation-VT-Drive-VFD-FC302-460V-25-HP.aspx
FC 300 Programming Guide
5-19 Terminal 37 Safe Stop
Option:
[5]
[6]
[7]
[8]
[9]
Choices 4–9 are only available when the MCB 112 PTC
thermistor card is connected.
®
MG33MD22 - VLT is a registered Danfoss trademark
Function:
Choice 4 is only available when the MCB 112
PTC thermistor card is connected.
PTC 1 Coasts Adjustable frequency drive when safe
Warning stop is activated (T-37 off). When safe stop
circuit is reestablished, the Adjustable
frequency drive will continue without manual
reset, unless a Digital Input set to PTC Card 1
[80] is still enabled. Choice 5 is only available
when the MCB 112 PTC thermistor card is
connected.
PTC 1 & This choice is used when the PTC option is
Relay A gated together with a stop button through a
safety relay to T-37. Coasts Adjustable
frequency drive when safe stop is activated.
Manual reset from LCP, digital input or serial
communication bus. Choice 6 is only available
when the MCB 112 PTC thermistor card is
connected.
PTC 1 & This choice is used when the PTC option is
Relay W gated together with a stop button through a
safety relay to T-37. Coasts Adjustable
frequency drive when safe stop is activated
(T-37 off). When safe stop circuit is reestab-
lished, the Adjustable frequency drive will
continue without manual reset, unless a
Digital Input set to PTC Card 1 [80] is (still)
enabled. Choice 7 is only available when the
MCB 112 PTC thermistor card is connected.
PTC 1 & This choice makes it possible to use a
Relay A/W combination of alarm and warning. Choice 8
is only available when the MCB 112 PTC
thermistor card is connected.
PTC 1 & This choice makes it possible to use a
Relay W/A combination of alarm and warning. Choice 9
is only available when the MCB 112 PTC
thermistor card is connected.
