1.4
Operator Control Panel
The operator control panel provides system controls and status
indicators. The controls are the Power, Halt, and Reset buttons. The
panel has a green power LED, a yellow halt LED, and four diagnostic
LEDs.
Figure 1–4 Control and Status Indicators
2
1
3
4
1
2
3 4
5
6
CAT0018A
DS20E Reference Guide
1-8
