Mode Overview, 2 Of 3 - Patton electronics SmartNode Series Software Configuration Manual

SmartWare Software Configuration Guide
Gateway H323 Gateway H323
gateway h323 <name> gateway h323 <name>
<host>(gw-h323)[<name>]# <host>(gw-h323)[<name>]#
Gateway SIP
gateway sip <name>
<host>(gw-sip)[<name>]#
Port Ethernet
port ethernet <slot> <port>
<host>(prt-eth)[<slot>/<port>]#
Port E1T1 or BRI Gateway H323
gateway h323 <name> port bri<slot> <port>
<host>(prt-bri)[<slot>/<port>]#
Gateway H323 Port FXO
gateway h323 <name> port fxo <slot> <port>
<host>(prt-fxo)[<slot>/<port>]#
Gateway H323 Port FXS
gateway h323 <name> port fxs <slot> <port>
<host>(prt-fxs)[<slot>/<port>]#
Gateway H323 Port Serial
port serial <slot> <port> gateway h323 <name>
<host>(prt-ser)[<slot>/<port>]#
Gateway H323 Port Virtual
port virtual <slot> <port> gateway h323 <name>
port virtual <slot> <port>
Gateway H323 System
gateway h323 <name>
<host>(gw-h323)[<name>]# <host>(sys)#
Radius Client
radius-client <name>
<host>(radius)[<name>]#
Subscriber PPP
subscriber ppp <name>
<host>(subscr)[<name>]#
Introduction
Gateways
PPPoE
<host>(pppoe)[<slot>/<port>]#
Gateway H323 Q.921
q921
<host>(q921)[<slot>/<port>]#
Gateway H323 Framerelay
<host>(frm-rel)#
Gateway H323 IC Voice
ic voice <slot>
<host>(ic-voice)[<slot>]#
Figure 12. Mode Overview, 2 of 3
B • Mode summary
PPPoE Session
session <session>
<host>(session)[<session>]#
Gateway H323 Q.931
gateway h323 <name> q931
<host>(q931)[<slot>/<port>]#
Gateway H323 PVC
gateway h323 <name> pvc <dlci>
<host>(pvc)[<dlci>]#
Other
