SmartWare Software Configuration Guide

Creating a transport interface

The interface command enters the configuration mode of a transport interface. If the requested interface does
not exist, a new one will be created. The no form of the command removes an existing transport interface.
Mode: Context SIP Gateway
Step
1
[node](sip-gw)[name]# [no] interface
<name>
Configuring the IP binding
The following commands specify the ip parameters for the transport layer. A listening socket for UDP and
TCP will be created according to the entered parameters. If the ip-interface parameter exists, the ip address of
the interface will be used. If the ip parameter does not exist, 0.0.0.0 will be used. If no port has been entered,
the default SIP port 5060 will be used. The no form of the command removes an existing binding.
Mode: Transport Interface
Step
1
[node](sip-if)[name]# [no] bind
or
[node](sip-if)[name]#bind interface ip-inter-
face
or
[node](sip-if)[name]#bind port <port>
or
[node](sip-if)[name]#bind interface ip-inter-
face port <port>
Configuring a priority
The priority is used if a SIP request is sent out over an ip interface to which the context SIP gateway has no
binding. In this case, the Contact (SIP/SDP) and VIA headers will get the ip address of the transport interface
with the highest priority. The lower the priority number, then the higher the priority. The highest priority is 0.
The no form of command sets the default priority to 0.
Mode: Transport Interface
Step
1
[node](sip-if)[name]# [no] priority <prior-
ity>
Context SIP Gateway configuration task list
Command
Command
Command
46 • Context SIP gateway overview
Purpose
Creates/Destroy sa transport interface or
enter configuration mode.
Purpose
Binds the transport interface to the IP layer or
removes an existing binding.
Purpose
Applies a priority to the transport interface.
