SmartWare Software Configuration Guide

Bind FXS ports to higher layer applications

An FXS port needs to be associated to an fxs interface in a CS context. The same mechanism of encapsulation
and binding is used as known for e.g. Ethernet ports (see
Procedure: To bind an FXS port to an FXS interface of a CS context
Mode: Port FXS
Step
1 node(config)#port fxs slot port
2 node(prt-fxs)[slot/port]#encap-
sulation cc-fxs
3 node(prt-fxs)[slot/port]#bind
interface interface
Configure country-specific FXS port parameters
Unlike ISDN, POTS is heavily country specific even though there is a good chance that a phone for one coun-
try works reasonably good in another country. Country specific settings are contained in a so-called fxs profile
which is integrated in the firmware of the SmartNode. It can be updated independently from the firmware by
means of tftp download.
As there are more than 190 countries, SmartWare does not support all country parameters, so make sure that
the country parameter for your country is available as a profile, before you begin operation.
Procedure: Configure country-specific FXS parameters
Mode: Port FXS
Step Command
1 node(config)#port
fxs slot port
2 node(prt-fxs)[slot/
port]#use profile
fxs profile
Bind FXS ports to higher layer applications
Command
Enter configuration mode for FXS port
Select a profile containing the country specific settings of the port attributes
(ring voltage etc.). The available country profiles are listed when entering
this command. The names listed are composed as follows:
ISO3166-1-Alpha-2 2 digit country code
Examples (currently available profiles):
• ch Switzerland
etsi ETSI EG 201 188 Configuration (Europe)
•
• gb Great Britain
nl
• Netherlands
• us United States of America/Canada
us-115vpp USA, higher ring voltatge (115 Vpp)
•
• za South Africa
The default profile (not displayed in the list when entering the command) is etsi.
"Interfaces, Ports, and Bindings"
Purpose
Enter configuration mode for FXS port
Sets the encapsulation for the port. cc-fxs designs
the encapsulation is a context CS interface
Binds the port to an interface in a CS context
Purpose
43 • FXS port configuration
on page 47).
