SmartWare Software Configuration Guide
Example: Display the ARP information.
node(cfg)#show arp
IP Interface eth0:
-----------------------------------------------------------------------------
Remote IP
-----------------------------------------------------------------------------
69.138.216.1
-----------------------------------------------------------------------------
IP Interface eth1:
-----------------------------------------------------------------------------
Remote IP
-----------------------------------------------------------------------------
10.9.10.20
10.9.10.12
10.9.10.2
10.9.10.166
10.9.10.10
10.9.10.11
10.9.10.3
-----------------------------------------------------------------------------
Configuring the IGMP Proxy
To enable the IGMP proxy functionality, you need to define which interface shall be used to receive multicast
streams (upstream interface) and to which interfaces the multicast streams shall be forwarded (downstream
interfaces). The router then listens on the downstream interfaces for IGMP join messages and forwards them
to the upstream interface.
Mode: Context IP
Step Command
1 node(ctx-ip)[ctx-name]#
interface <if-name>
2 node(if-ip)[if-name]# igmp
interface-type proxy-
upstream
3 node(ctx-ip)[ctx-name]#
interface <if-name>
4 node(if-ip)[if-name]# igmp
interface-type proxy-
downstream
5

Configuring the IGMP Proxy

Remote MAC
00:01:5C:22:46:C2
Remote MAC
00:11:1A:4C:B1:1C
00:02:2D:BB:13:FB
00:09:5B:6F:93:06
00:09:5B:41:30:33
00:80:AD:78:BB:DD
00:50:04:74:94:6C
00:09:5B:53:D2:B0
Go to the IP interface, which shall act as the IGMP proxy
upstream interface
Define the interface as the IGMP proxy upstream interface
Go to an IP interface, which shall act as an IGMP proxy down-
stream interface
Define the interface as an IGMP proxy downstream interface
Repeat steps 3 & 4 for any additional interface, which shall act
as an IGMP proxy downstream interface.
State TTL
reachable 342s
State TTL
reachable 408s
reachable 326s
reachable 518s
stale 556s
reachable 394s
reachable 433s
reachable 521s
Purpose
10 • IP interface configuration
TxReq RxRep Usage
2 2 12
TxReq RxRep Usage
1454 1451 67939
533 571 16819
0 515 1054
2 9 2277
0 2 1982
1 1
0 2 18
2
129
