SmartWare Software Configuration Guide
Note Verify that you have configured the dial-tone for the country in which the
SmartNode is installed. (see chapter 42,
If the dial-tone is not configured for the proper country, the FXO interface
will not detect when the remote FXS switch is sending dial-tone.
Configuring the number of rings to wait before answering the call (optional)
An FXO port identifies an incoming call by detecting the ring from the FXS switch. The
configurable parameter which selects the number of rings before answering the incoming call, that is, before
going off-hook and establishing the call. The minimum value for
ber of zero, the FXO interface never answers an incoming call.
Due to variations between countries, the proper setting may be 1 or 2. In the USA the Caller-ID (CLID) is sent
to the FXO port between the first and second ring, so a ring-number of 2 would be appropriate. On the other
hand, numerous countries send the CLID prior to the first ring, so the default setting of 1 would be satisfactory.
Mode: Interface FXO
Step Prompt, command & response
1 node>
2 node>enable
node#
3 node#configure
node(cfg)#
4 node(cfg)#context cs
node(ctx-cs)[switch]#
5 node(ctx-cs)[switch]#interface fxo if-name Enter the Interface FXO configuration mode
node(if-fxo)[if-name]#
6 node(if-fxo)[if-name]#ring-number count
Example: Configure the ring number to wait for CLID by setting the count to 2. The name of the specific FXO
interface is pstn-local.
node>enable
node#configure
node(cfg)#context cs
node(ctx-cs)[switch]#interface fxo pstn-local
node(if-fxo)[pstn-local]#ring-number 2
You can verify the change in configuration by using the
FXO interface configuration task list
36 • FXO interface configuration
"Tone configuration"
ring-number
Basic prompt in Operator Exec mode
Enters Administration execution mode
Response: The prompt in administration execu-
tion mode is the #
Enters the Configure configuration mode
Response: The prompt in the Configure configu-
ration mode is (cfg)#
Enters the Context CS configure mode
Response: The prompt in the Context CS configu-
ration mode is (ctx-cs)[switch]#
Response: The prompt in the Interface FXO con-
figuration mode is (if-fxo)[if-name]#
Specifies the number of rings to wait before
going off-hook. Default = 1 ring.
show running-config
on page 524).
ring-number
is zero (0). With a ring-num-
Purpose
command.
is a
416
