SmartWare Software Configuration Guide

Introduction

This chapter provides an overview of the serial port and describes the tasks involved in its configuration
includes the following sections:
• Serial port configuration task list
• Configuration tasks
• Examples
The V.35 standard is recommended for speeds up to 48 kbps, although in practice it is used successfully at 4
Mbps. The X.21 standard is recommended for data interfaces transmitting at rates up to 2 Mbps and is used
primarily in Europe and Japan.
The synchronous serial interface supports full-duplex operation and allows interconnection to various serial
network interface cards or equipment. Refer to the getting started guide included with your SmartWare for
specific information regarding the connector pinout and the selection of cables to connect with third-party
equipment.
Serial port configuration task list
Perform the tasks in the following sections to configure a synchronous serial interface:
• Disabling an interface (see
• Enabling an interface (see
• Configuring the serial encapsulation type (see
• Configuring the hardware port protocol (see
• Configuring the active clock edge (see
• Configuring the baudrate

Disabling an interface

Before you replace a compact serial cable or attach your SmartNode to other serial equipment, use the
command to disable the serial interfaces. This prevents anomalies and hardware faults. When you
shutdown
shut down an interface, it has the state CLOSED in the
Note
Use the
figuration procedure.
This procedure describes how to shut down a serial interface
Mode: Administrator execution
Step
1 node(cfg)#port serial slot port
2 node(prt-ser)[slot/port]#shutdown
3 node(prt-ser)[slot/port]#show port serial Displays the serial interface configuration.

Introduction

page 169)
page 170)
page
page 172)
command to enable the serial interface after the con-
no shutdown
Command
page 171)
171)
show port serial
Selects the serial interface on slot and port
Shuts the selected interface down
14 • Serial port configuration
command display.
Purpose
169
