SmartWare Software Configuration Guide
node(cfg)#context cs
node(ctx-cs)[switch]#interface h323 MyH323If
node(if-h323)[MyH323If]#no status-inquiry
Procedure: To change the default status inquiry interval
Mode: Interface H.323
Step
1
node(if-h323)[if-name]#status-inquiry
timeout seconds
Example: Disable status inquiries
The following example
the status inquiry interval for the H.323 interface MyH323If to 120 seconds.
node>enable
node#configure
node(cfg)#context cs
node(ctx-cs)[switch]#interface h323 MyH323If
node(if-h323)[MyH323If]#status-inquiry timeout 120

Enabling or disabling overlapped sending support in H.323

This procedure disables support for overlapped sending on an H.323 interface. Call process is established more
quickly with Overlapped Sending because the call routing occurs simultaneously while the user keys in the
address.
Mode: interface h323 <if-name>
Step
1
[name](if-h323)[gw-name]#no overlap-
sending-support

AOC-D Support for H.323

The H.323 gateway is able to accept and send Advice of Charge during the call (AOC-D) messages according
to the ITU-T standard Q.956. Facility Information Elements (IEs) in the Q.931 portion of the protocol are
used to transport AOC-D PDUs. (Refer to "Chapter 28: ISDN interface configuration", section "ISDN
Advice of Charge support.")
You can enable/disable reception and transmission of AOC-D messages separately on each H.323 interface.
When reception is enabled, AOC-D messages received in incoming H.323 FACILITY messages are forwarded
to the ISDN side of the call. In addition to the H.323 interface, AOC support must also be enabled on the
ISDN interface (see ISDN Advice Of Charge support section of Chapter 28 ISDN interface configuration of
the Software Configuration Guide).
When transmission is enabled, AOC-D messages received from the ISDN side of the call are sent as H.323
FACILITY to the remote terminal or gatekeeper.
H.323 interface configuration task list
Command
Command
38 • H.323 interface configuration
Purpose
Changes the status inquiry interval on the
interface to the specified number of seconds
Purpose
Disables overlapped-sending support.
434
