SmartWare Software Configuration Guide
it should create and which IP addresses/ports it must modify (e.g. for voice connections in addition to signal-
ing connections). It performs this task for the protocol FTP. Other protocols such as H.323 and SIP cannot
traverse the SmartWare NAPT.
NAT/NAPT configuration task list
To configure the NAT/NAPT component, perform the tasks in the following sections:
• Creating a NAPT profile (see
• Activating NAT/NAPT (see
• Displaying NAT/NAPT configuration information (see
Creating a NAPT profile
A NAPT profile defines the behavior of the NAT/NAPT component, comprising all four types of NAT/NAPT
(this profile is called 'NAPT profile' and not 'NAT/NAPT profile for historical reasons). Several NAPT profiles
are admissible but there is only one NAT/NAPT component.
Procedure: To create a NAPT profile and to configure the required types of NAT/NAPT
Mode: Configure
Step
1 node(cfg)#profile napt name
2 node(pf-napt)[name]#range local-
(optional) ip-range-start local-ip-range-stop
global-ip
3 node(pf-napt)[name]#static
(optional) { udp | tcp } local-ip local-port
[global-ip] [global-port]
4 node(pf-napt)[name]#range local-
(optional) ip-range-start local-ip-range-stop
global-ip-start global-ip-stop

NAT/NAPT configuration task list

page 134)
page 134)
Command
page 137)
Purpose
Creates the NAPT profile name and activates the
basic behavior of the Dynamic NAPT
Configures and activates the enhanced behavior of
the Dynamic NAPT: local-ip-range-start and local-ip-
range-stop define the subset of local hosts that use
the global NAT address global-ip to access to global
network.
(max. 20 entries)
The IP ranges of different Dynamic NAPT entries must
not overlap each other.
Creates a Static NAPT entry: local-ip/local-port is
mapped to global-ip/global-port. If global-port is
omitted, local-port is used on both sides. If global-ip
is omitted, the global address is the address of the
global interface.
(max. 20 UDP and 20 TCP entries)
Configures and activates the Dynamic NAT: local-ip-
range-start and local-ip-range-stop define the subset
of local hosts that use an address from the global
NAT address pool to access to global network. glo-
bal-ip-start and global-ip -stop define the global NAT
address pool.
(max. 20 entries)
The IP ranges of different Dynamic NAT entries must
not overlap each other.
11 • NAT/NAPT configuration
134
