SmartWare Software Configuration Guide

Activate NAT/NAPT

To activate a NAT/NAPT component, bind its NAPT profile to an IP interface. This binding identifies the
global interface of the respective NAT/NAPT component. All other IP interfaces are local relative to this NAT/
NAPT.
Note
If both a NAPT profile and an ACL profile are bound to the same IP inter-
face, the ACL (Access Control List) acts on the local side of the NAT/
NAPT component.
Procedure: To activate a NAT/NAPT component
Mode: Configure
Step
1 node(cfg)#context ip router
2 node(ctx-ip)[router]#interface
name
3 node(if-ip)[name]#use profile
napt profile
Example: Configuring NAPT Interface
The following example shows how to activate a NAT/NAPT component with the NAPT profile access on the
IP interface lan.
node(cfg)#context ip router
node(ctx-ip)[router]#interface lan
node(if-ip)[lan]#use profile napt access
Displaying NAT/NAPT configuration information
Two commands are available to display an existing NAPT profile. There is no command yet to display the
dynamic entries of a NAT/NAPT component.
Procedure: To display NAT/NAPT configuration information
Mode: Configure
Step
1 node(cfg)#show profile napt
2 node(cfg)#show profile napt
name
or
node(cfg)#show napt interface
name
NAT/NAPT configuration task list
Command
Command
Purpose
Selects the IP router context
The NAPT profile shall be used on the interface name
Defines that the NAPT profile profile shall be used on
the interface name
Purpose
Displays the available NAPT profiles
Displays the NAPT profile name
or
Displays the NAPT profile bound to the IP interface
name
11 • NAT/NAPT configuration
137
