SmartWare Software Configuration Guide
Mode: Administrator execution
Step Command
1 node(cfg)#system contact name
2 node(cfg)#system location location
3 node(cfg)#system hostname hostname Sets the system hostname and command line prompt
If any of the command options name, location, or hostname has to be formed out of more than one word, the
information is put in "double quotes".
Note Enter an empty string "" to get rid of any of the system settings.
The MIB-II system group values are accessible for reading and writing via the following SNMP objects:
• .iso.org.dod.internet.mgmt.mib-2.system.sysContact
• .iso.org.dod.internet.mgmt.mib-2.system.sysName
• .iso.org.dod.internet.mgmt.mib-2.system.sysLocation
After setting these values according to 1 through 3 any SNMP MIB browser application should read the values
using a or
get get-next
The procedure to use the SNMP MIB browser is:
• Enter the community string public into the Community field in the upper right corner of the window. For
safety reasons each entered character is displayed with a "*".
• Access any of the supported MIB system group object by using the GetNext button from the button bar of
the window.
Setting basic system information
command as shown in figure
Purpose
Sets the contact persons name
Sets the system location
40.
25 • SNMP configuration
