SmartWare Software Configuration Guide
Mode: Configure
Step
1 node(cfg) #show ppp links [ level ]
2 node(cfg) #show ppp networks [ level ]
3 node(cfg) #show pppoe [ name ]
4 node(cfg) #show port interface name
5 node(cfg) #show port ethernet slot port
6 node(cfg) # [no] debug ppp [ all | ... ]
7 node(cfg) # [no] debug pppoe [ all | ... ] Enables all or a particular PPPoE debug monitor.
PPP configuration task list
Command Purpose
Displays status and configuration information of
the Link Control Protocol (LCP) and the authentica-
tion protocol(s) (PAP and/or CHAP). Check
whether the states of the two protocols are
'Opened'.
level specifies to level of details displayed (1..4,
default is 1).
Displays status and configuration information of
the Network Control Protocol(s) (NCP), in particu-
lar the IP Control Protocol (IPCP). Check whether
the states of this protocol is 'Opened'.
Under 'Local configuration options', you find the IP
address proposed by this SmartNode and under
'Local acknowledged options', the IP address
assigned by the remote peer.
level specifies to level of details displayed (1..4,
default is 1).
Displays status, configuration information, and sta-
tistics of PPPoE in general and of the PPPoE ses-
sion(s). Check whether state of the respective
session is 'Opened'.
level specifies to level of details displayed (1..4,
default is 1).
Displays status and configuration information of the
IP interface at which a PPP connection terminates.
Check whether state of the interface is 'OPENED'.
Under 'Local IP Address', you find the IP address
assigned to the IP interface. If it does not corre-
spond to the IP address assigned by the PPP
remote peer, check whether the 'ipaddress' of the
IP interface is set to 'unnumbered'.
Displays status and configuration information of the
Ethernet/serial port over which a PPP connection/
PPPoE sessions runs. Check whether state of the port
is 'OPENED' and whether the encapsulation is set to
'pppoe' or 'multi' (only for Ethernet ports).
Enables all or a particular PPP debug monitor.
