SmartWare Software Configuration Guide
Procedure: To create an IPsec policy profile
Mode: Configure
Step
1 node(cfg)#profile ipsec-policy-man-
ual name
2 node(pf-ipstr)[name]#use profile
ipsec-transform name
3 node(pf-ipstr)[name]#session-key
optional
{ inbound | outbound }
{ ah-aauthentication | esp-
authentication | esp-encryption } key
4 node(pf-ipstr)[name]#spi
{ inbound | outbound } { ah | esp } spi
5 node(pf-ipstr)[name]#peer ip-address
6 node(pf-ipstr)[name]#mode
{ tunnel | transport }
VPN configuration task list
Command Purpose
Creates the IPsec policy profile name
Selects the IPsec transformation profile to be
applied
Sets a key for encryption or an authenticator for
authentication, either for inbound or outbound
direction. The key shall consist of hexadecimal
digits (0..9, A..F); one digit holds 4 Bit of key
information.
The key setting must match definitions in the
respective IPsec transformation profile. In particu-
lar, the length of the key or authenticator must
match the implicit (see section
on page 361 and "Encryption"
explicit specification.
Keys must be available for inbound and out-
bound directions. They can be different for the
two directions. Make sure that the inbound key
of one peer matches the outbound key of the
other peer.
Sets the SPI for encryption (esp) or authentication
(ah), either for inbound or outbound direction.
The SPI shall be a decimal figure in the range
32
1..2 –1.
SPIs must be available for encryption and/or
authentication as specified in the respective IPsec
transformation profile.
SPIs must be available for inbound and outbound
directions. They can be identical for the two
directions but must be unique in one direction.
Make sure that the inbound SPI of one peer
matches the outbound SPI of the other peer.
Sets the IP address of the peer
Note The peers of the secured
communication must have
static IP address. DNS reso-
lution is not available yet.
Selects tunnel or transport mode
32 • VPN configuration
"Authentication"
on page 361) or
