Sample configurations
The following sample configurations establish IPsec connections between a SmartNode and a Cisco router. To
interconnect two SmartNodes instead, derive the configuration for the second SmartNode by doing the follow-
ing modifications:
• Swap 'inbound' and 'outbound' settings
• Adjust the 'peer' setting
• Swap the private networks in the ACL profiles
• Adjust the IP addresses of the LAN and WAN interfaces
• Adjust the route for the remote network

IPsec tunnel, DES encryption

SmartNode configuration
profile ipsec-transform DES
esp-encryption des-cbc 64
profile ipsec-policy-manual VPN_DES
use profile ipsec-transform DES
session-key inbound esp-encryption 1234567890ABCDEF
session-key outbound esp-encryption FEDCBA0987654321
spi inbound esp 1111
spi outbound esp 2222
peer 200.200.200.1
mode tunnel
profile acl VPN_Out
permit ip 192.168.1.0 0.0.0.255 172.16.0.0 0.0.255.255 ipsec-policy VPN_DES
permit ip any any
profile acl VPN_In
permit esp any any
permit ah any any
permit ip 172.16.0.0 0.0.255.255 192.168.1.0 0.0.0.255
deny ip any any
context ip router
interface LAN
ipaddress 192.168.1.1 255.255.255.0
interface WAN
ipaddress 200.200.200.2 255.255.255.252
use profile acl VPN_In in
use profile acl VPN_Out out
context ip router
route 0.0.0.0 0.0.0.0 200.200.200.1 0
route 172.16.0.0 255.255.0.0 WAN 0
