Debugging FXS Signaling

Overview: FXS debug monitors
unit#debug ccfxs
unit#debug fxs
unit#debug media-gateway control
unit#show call-control provider name
[detail detail]

Verify an incoming call

Make sure an incoming call is entering correctly context CS. In this example, a POTS terminal connected to
an FXS port goes off hook and places a call. The port is bound to a context CS interface named PHONE. The
debug output below shows a normal (working) call setup sequence.
unit>enable
unit#configure
unit(cfg)#debug ccfxs
unit(cfg)#debug fxs
unit(cfg)#09:00:11
09:00:11 FXS
09:00:11 FXS
09:00:11 FXS
09:00:11 FXS
09:00:11 CFXS
09:00:11 CFXS
09:00:11 CFXS
09:00:11 FXS
09:00:11 FXS
09:00:13 CFXS
09:00:13 CFXS
09:00:43 CFXS
09:01:01 CFXS
09:01:01 CFXS
09:01:01 CFXS
Explanation:
•
unit(cfg)#09:00:11
•
09:00:11 CFXS > [EP PHONE] Change state to DIAL-TONE.
•
09:00:13 CFXS > [EP PHONE] Change state to DIALING.
stops.
Debugging call signaling
Command
FXS > [0 1] Off hook.
> [0 1] Notifying off hook.
> FXS-00/01: state=on-hook, event=off-hook
> [0 1] Set state to 'Active'
> FXS-00/01: new state=filtering-events
> [EP PHONE] Change state to DIAL-TONE.
> [EP PHONE] Change datapath direction to receive-only.
> [EP PHONE] Play tone: dial-tone
> FXS-00/01: state=filtering-events, event=timeout
> FXS-00/01: new state=off-hook
> [EP PHONE] Change state to DIALING.
> [EP PHONE] Stop tone.
> [EP PHONE] Play tone: ringback-tone
> [EP PHONE] Change state to CONNECTED.
> [EP PHONE] Stop tone.
> [EP PHONE] Change datapath direction to send/receive.
FXS > [0 1] Off hook.
Prints all operations on the FXS interfaces (high-
level).
Prints all operations on the FXS ports (low-level).
Prints the dialed digits.
Shows the status of an FXS interface in context CS
(call control part of FXS signaling). Shown are all
calls currently ongoing on the interface, with their
call states, signaling peers and voice data path
parameters.
name is the name of the FXS interface. Use detail 5
for most verbose output.
: The phone went off-hook
: The dial-tone is played.
: The first digit has been touched. Dial-tone
