Enabling 'Early-Proceeding' On H.323 Interfaces; Enabling The Early Call Connect (Optional) - Patton electronics SmartNode Series Software Configuration Manual

SmartWare Software Configuration Guide
Mode: Interface H.323
Step
1
node(if- h323)[if-name]#clip-clir-support Enables CLIP/CLIR support on the H.323
Example: Enable CLIP/CLIR support
The following example shows how to enable CLIP/CLIR support on the H.323 interface MyH323If.
node>enable
node#configure
node(cfg)#context cs
node(ctx-cs)[switch]#interface h323 MyH323If
node(if-h323)[MyH323If]#clip-clir-support

Enabling 'early-proceeding' on H.323 interfaces

The
early-proceeding
the gateway will immediately reply with an H.225 (H.323) call-proceeding message in response to a received
H.225 (H.323) setup message without waiting for a response from the destination.
Mode: interface h323 <if-h323>
Step
1
[name](if-h323)[if-name]#early-proceeding Enables the early-proceeding feature.
Example: Enable early call disconnect
The following example shows how to enable early call disconnect on an H.323 interface named MyH323If.
node>enable
node#configure
node(cfg)#context cs
node(ctx-cs)[switch]#interface h323 MyH323If
node(if-h323)[MyH323If]#early-disconnect

Enabling the early call connect (optional)

The command can be enabled to open a data path before the call is connected to play inband
early-connect
information from the ISDN side.
Mode: interface h323
Step
1
[name](if-h323)[name]#early-connect
H.323 interface configuration task list
Command
command can enable the early-proceeding feature on H.323. If this feature is enabled,
Command
Command
38 • H.323 interface configuration
Purpose
interface
Purpose
Purpose
Enables the early-connect feature.
431
