You can create a mapping table that examines and modifies a specific kind of property, e.g. the called party
number. In this case you have to specify an input-type of called-e164 and an output-type of called-164. If you
want to replace both, the called and the calling party property with the same mapping table, you can create a
mapping table with input-type e164 and output-type e164, i.e. without prefixing the input- and output-type
with "called-".
The name of the mapping table is unique inside the context and serves as identifier for referencing the map-
ping table from other routing tables. Almost every type explained with the routing table above can be used as
input and output-type of a mapping table.
Type
called-e164
calling-e164
e164
called-type-of-number
calling-type-of-number Selects an entry based on the calling party
type-of-number
called-numbering-plan Selects an entry based on the called party
calling-numbering-plan Selects an entry based on the calling party
numbering-plan
Call router configuration task list
Table 20. Mapping table types
Description Input-Type
Select an entry based on the called party
E.164 number. You can use wildcards to
summarize entries.
Select an entry based on the calling party
E.164 number. You can use wildcards to
summarize entries.
If the output-type is also a generic kind of
property, this mapping table is applied to
both, this calling-e164 and the called-e164
property.
Select an entry based on the called party
number type. ISDN distinguishes different
type of numbers.
number type. ISDN distinguishes different
type of numbers.
If the output-type is also a generic kind of
property, this mapping table is applied to
both, this calling-type-of-number and the
called- type-of-number.
numbering plan. ISDN distinguishes differ-
ent numbering plans.
numbering plan. ISDN distinguishes differ-
ent numbering plans.
If the output-type is also a generic kind of
property, this mapping table is applied to
both, this calling-numbering-plan and the
called-numbering-plan.
40 • Call router configuration
Description Output-Type
Modifies the called party E.164 number.
If the input-type is a called-e164 or a
calling-e164 type, you can use replace-
ment operators to use parts of the lookup
key.
Modifies the calling party E.164 num-
ber. If the input-type is a called-e164 or
a calling-e164 type, you can use
replacement operators to use parts of the
lookup key.
If the input-type is also a generic kind of
property, this mapping table is applied
to both, the calling-e164 and the called-
e164 property.
Sets the called party number type.
Sets the calling party number type.
If the input-type is also a generic kind of
property, this mapping table is applied
to both, the calling-type-of-number and
the called-type-of-number property.
Sets the called party numbering plan.
Sets the calling party numbering plan.
If the input-type is also a generic kind of
property, this mapping table is applied
to both, the calling-numbering-plan and
the called-numbering-plan property.
477
