SmartWare Software Configuration Guide
Mode: Context CS
Step Command
1 [name] (ctx-cs)[switch]#[no] ser-
vice bridge BRIDGE1
2 [name] (svc-bridg)[BRIDGE1]#port
DIALER
3 [name] (port)[DIALER]# dial persis-
tent 123 dest-interface REMOTE
4 [name] (svc-bridg)[BRIDGE1]#port
LISTENER
5 [name] (port)[DIALER]# no dial
Configuration Example:
context cs switch
routing-table called-e164 DISPATCH
route 1 dest-service BRIDGE1.dialer
...
service bridge BRIDGE1
port listener
mode listening
no shutdown
port dialer
mode dial-persistent 1 dest-interface REMOTE
no shutdown
interface h323 REMOTE
bind gateway h323
route call dest-table DISPATCH
remote 172.16.32.37
interface fxs PHONE1
route call dest-service BRIDGE1.listener
Configuring the service second-dialtone
If a call is routed into the service second-dialtone, the service establishes the call and plays a dial tone to the
caller.When a call is entering the service it is first routed to the configured destination. In case the call cannot
be placed, the service plays the second dial-tone or the configured announcement to the caller until the caller
enters the first DTMF digit.
Call router configuration task list
Enters the bridge service configuration mode / deletes a
bridge service.
Creates a port on the service that can accept or spawn calls
(the max number of ports is currently limited to two)
Configures the port to actively dial the called-party "123" to
the destination REMOTE. This connection is kept open until
the service is shut down, or a "no dial" command is issued. If
the remote side terminates the connection, the port tries to
reconnect. As soon as the connection is established, the call
is connected to all other calls present on the service.
Creates a port on the service that can accept or spawn calls
(the max number of ports is currently limited to two)
Without entering a "dial" command, or by specifying "no
dial", this port does not dial, but listen for incoming calls. If a
call comes in, it is automatically connected to all other calls
present on the service.
40 • Call router configuration
Purpose
508
