SmartWare Software Configuration Guide
Mode: Interface RBS
Step
1
node(if-rbs)[if-name]#use profile pstn pro-
file-name
Configuring an alternate Tone-Set profile
The Tone-Set profile contains the mapping of the different Call Progress Tones like Dial-Tone, Ringback-Tone
or Release-Tone to programmed tone sequences. Dependent on the configuration, the RBS protocols must be
able to detect inband played Dial or Release Tones. Therefore it is important, both communication parties
using the same tone specifications. For details how to setup and alternate Tone-Set profile, please consult chap-
ter 42, "Tone configuration"
There is a Tone-Set profile named default, which always exists in the system. If no different Tone-Set profile
name is explicitly configured on the RBS interface, the profile default is used.
Mode: Interface RBS
Step
1
node(if-rbs)[if-name]#use profile tone-set
profile-name
Configuring B-Channel allocation strategy
If a group of timeslots is bound to the interface and a call is originated by the Call Control, the B-Channel
allocation strategy defines if the highest available timeslot number must be chosen for initiating the outgoing
call or the lowest one. For incoming calls over TDM this command has no effect because the timeslot has
already been selected by the remote party.
Mode: Interface RBS
Step
1
node(if-rbs)[if-name]#bchan-number-
order {ascending | descending}
Configuring additional disconnect signals
Most of the RBS protocols define a ABCD-Bit pattern can be sent to indicate a call disconnection to the
remote party. In case of the Loop Start protocol where the exchange side terminates the call, this is not possible.
This protocol is really similar to an analog telephony line where the subscriber will be informed with a release
tone about a call release. With this command it is possible to configure additional signals must be interpreted
as a disconnect event.
Creating/Deleting a RBS interface
Command
on page 524.
Command
Command
37 • RBS interface configuration
Purpose
Defines an alternate PSTN profile to be used for
this RBS interface/Reverts the setting to its default
(use profile PSTN default)
Purpose
Defines an alternate Tone-Set profile to be used for
this RBS interface/Reverts the setting to its default
(use profile Tone=-Set default)
Purpose
Defines the B-Channel allocation strategy
Default: descending
