SmartWare Software Configuration Guide
Mode: Operator execution
Step
1
node#[no] debug cas {event | error}
Mode: Operator execution
Step
1
node#[no] debug rbs {event | error}
RBS Configuration Examples
Example: Configuring RBS Ground Start on a E1T1 port
port e1t1 0 0
port-type t1
clock slave
linecode b8zs
framing esf
encapsulation rbs
rbs
protocol ground-start subscriber
encapsulation cc-rbs
bind interface RBS00 switch
port e1t1 0 0
no shutdown
Example: Configuring different RBS protocols with a Channel Group on an E1T1 port
port e1t1 0 0
port-type t1
clock slave
linecode b8zs
framing esf
encapsulation channelized
channel-group RBS_GROUP_1_8
timeslots 1-8
encapsulation rbs
rbs
protocol eam-wink-start
encapsulation cc-rbs
bind interface RBS00_1_8 switch
channel-group RBS_GROUP_9_16
timeslots 9-16
encapsulation rbs
rbs
protocol eam-immediate-start
encapsulation cc-rbs
bind interface RBS00_9_16 switch
RBS configuration task list
Command
Command
20 • RBS configuration
Purpose
Enables/Disables CAS event/error monitor
Purpose
Enables/Disables RBS event/error monitor
226
