SmartWare Software Configuration Guide
Example: Configuring the active clock edge
The following example enables to send data on the negative edge on slot 0 and port 0. Check that Transmit
Clock is set to inverted in the command output of
node(cfg)#port serial 0 0
node(prt-ser)[0/0]#transmit-data-on-edge negative
node(prt-ser)[0/0]#show port serial
Serial Interface Configuration
------------------------------
Port
State
Hardware Port
Transmit Edge
Port Type
CRC Type
Max Frame Length: 2048
Recv Threshold
Encapsulation
Configuring the baudrate
A DCE interface has to provide the signal clocks. The desired baudrate can be configured.
Note
Only available on certain devices.
This procedure describes how to set the baudrate for the serial interface.
Mode: Port serial
Step
1 node(prt-ser)[slot/port]# baudrate
baudrate
Example: Configuring baudrate to 64,000 bps
The following example configures a baudrate of 64,000 bps on the serial interface. Verify that the command
show port serial detail 5
baudrate of the selected hardware.
node(cfg)#port serial 0 0
node(prt-ser)[0/0]#transmit-data-on-edge negative
node(prt-ser)[0/0]#show port serial detail 5
HDLC Driver: 0x8496b8
=====================
Slot:
Number of Ports:
Port: serial 0 0 0
------------------
Serial port configuration task list
: serial 0 0 0
: CLOSED
: X.21
: inverted
: DTE
: CRC-16
: 1
: framerelay
Command
output displays the correct baudrate. True baudrate in the Status section shows the
0
1
.
show port serial
Configures the baudrate for the serial interface.
14 • Serial port configuration
Purpose
173
