SmartWare Software Configuration Guide
In this routing table two default routes (0.0.0.0/0) are defined. The first default route is valid for packets of the
class local-voice only. The second default route is valid for all packets. Thus voice packets generated locally
(traffic-class local-voice) will travel via the gateway (Nexthop) 172.16.32.1. All other packets will travel via the
gateway (Nexthop) 172.16.32.2.
NOTE: If the second default route was missing, there would be no default route for packets of traffic-class
other than local-voice.
The following modified commands are used with policy routing:
Route—refer to the 'route' command in the subsection
chapter.
Ping—refer to the 'ping' command described in the subsection
on page 125 in Chapter 10: IP interface configuration.
Traceroute—refer to the 'traceroute' command described in the subsection
ter 10: IP interface configuration.

Examples

Basic static IP routing example

Figure 37 shows an Internetwork consisting of three routers, a SmartNode device in the middle, and the four
autonomous networks, with network addresses 10.1.5.0/16, 172.16.40.0/24, 172.17.100.0/24, and 10.2.5.0/
16. The SmartNode shall be configured for the following IP routing scenario:
All packets for the Workstation with IP address 10.1.5.10 shall be forwarded to the next-hop router Calvin. All
packets for network 10.2.5.0/16 shall be forwarded to the next-hop router Hobbes.
10.1.5.2/16
Hub
Hub
10.1.5.10/16
Workstation

Examples

172.16.40.2/24
lan
Calvin
172.16.40.1/24
Figure 37. Internetwork with three routers and four networks
22 • Basic IP routing configuration
"Configuring static IP routes"
"Testing connections with the ping command"
"Traceroute"
172.17.100.2/24
wan
Node
Node
172.17.100.1/24
on page 235 in this
on page 128 in Chap-
10.2.5.2/16
Hobbes
238
