Configuring A Vlan - Patton electronics SmartNode Series Software Configuration Manual

SmartWare Software Configuration Guide
Mode: Configure
Step
1 [name] (cfg)# context ip
2 [name] (ctx-ip)[router]# interface <ip-if-1-name>
3 [name] (if-ip)[ <ip-if-1-name>]# ipaddress <ip-
address-1> <subnet-mask-1>
4 [name] (if-ip)[ <ip-if-1-name>]# interface <ip-if-2-name>
5 [name] (if-ip)[ <ip-if-2-name>]# ipaddress <ip-address-2>
<subnet-mask-2>
6 [name] (if-ip)[ <ip-if-2-name>]# port ethernet <slot>
<port>
7 [name] (prt-eth)[<slot>/<port>]# encapsulation ip
8 [name] (prt-eth)[<slot>/<port>]# bind interface <ip-if-
1-name>
9 [name] (prt-eth)[<slot>/<port>]# bind interface <ip-if-
2-name>
10 [name] (prt-eth)[<slot>/<port>]# no shutdown
Configuring a VLAN
By default no VLAN ports are configured on an Ethernet port. One or more VLAN ports can be created on
each Ethernet port.
You must bind the VLAN port to an existing IP interface. When executing the
interface must exist.
For incoming VLAN packets each of the 8 possible layer 2 class of services (CoS) can be mapped to a traffic
class. Unless otherwise specified all CoS values map to the default traffic class.
By default all VLAN ports are initially disabled. They can be enabled with the
corresponding Ethernet port must also be enabled for the VLAN port to work. If the Ethernet port is disabled,
all associated VLAN ports are also disabled.
When a VLAN port is closed, the IP interface that is bound to this port is also closed. All static routing entries
that are using this interface change their state to invalid and all dynamic routing entries will be removed from
the route table manager.
Ethernet port configuration task list
Command
12 • Ethernet port configuration
Purpose
Enter the IP context configuration
mode.
Create the first IP interface.
Set the IP address for the first IP inter-
face
Create the second IP interface.
Set the IP address for the second IP
interface
Enter Ethernet port configuration
mode
Set the encapsulation to IP
Bind the port to the first IP interface
Bind the port to the second IP inter-
face
Enable the Ethernet port
command, the requested
bind
no shutdown command. The
143
