PIM Configuration
Examples
PIM-DM Configuration
Example
To do...
View the content of the PIM
routing table
View the RP information
Reset PIM control message
counters
Network requirements
Receivers receive VOD information through multicast. The receiver groups of
■
different organizations form stub networks, and one or more receiver hosts
exist in each stub network. The entire PIM domain operates in the dense mode.
Host A and Host C are multicast receivers in two stub networks N1 and N2.
■
Router D connects to the network that comprises the multicast source (Source)
■
through Ethernet 1/0.
Router A connects to N1 through Ethernet 1/0, and to Router D through Serial
■
2/0.
Router B and Router C connect to N2 through their respective Ethernet 1/0,
■
and to Router D through their respective POS 5/0.
IGMPv2 is required on Router A, Router B, Router C and hosts in N1, and N2.
■
Router B is the IGMP querier on the multi-access subnet.

PIM Configuration Examples

Use the command...
display pim [ vpn-instance
vpn-instance-name | all-instance ]
routing-table [ group-address [ mask
{ mask-length | mask } ] | source-address
[ mask { mask-length | mask } ] |
incoming-interface [ interface-type
interface-number | register ] |
outgoing-interface { include | exclude
| match } { interface-type
interface-number | register } | mode
mode-type | flags flag-value | fsm ] *
display pim [ vpn-instance
vpn-instance-name | all-instance ]
rp-info [ group-address ]
reset pim [ vpn-instance
vpn-instance-name | all-instance ]
control-message counters [ interface
interface-type interface-number ]
1193
Remarks
Available in any
view
Available in any
view
Available in user
view
