To do...
Configure the remote PE as
the peer
Specify the interface for TCP
connection
Enter address family view
Allow the local AS number to
appear in the AS_PATH
attribute of a received route
and set the maximum number
of repetitions
Enable a peer or peer group
for an address family and
enable the exchange of BGP
routing information of the
address family
Add a peer into an existing
peer group
Configure the system to use
the local address as the next
hop of a route to be
advertised to a specified peer
or peer group
Configure the system to be
the RR and set a peer or peer
group as the client of the RR
Enable VPN target filtering for
received VPNv4 routes
Enable route reflection
between clients
Specify the cluster ID of the
RR
Create an RR reflection policy rr-filter
n
For information about BGP-L2VPN address family, refer to
Configuration" on page
Configuring specific routing features for BGP-VPNv4 subaddress family
Follow these steps to configure specific routing features for BGP-VPNv4
subaddress family:
To do...
Enter system view
Enter BGP view
Use the command...
peer ip-address as-number
as-number
peer ip-address
connect-interface
interface-type
interface-number
ipv4-family vpnv4
l2vpn-family
peer { group-name |
ip-address } allow-as-loop
[ number ]
peer { group-name |
ip-address } enable
peer ip-address group
group-name
peer { group-name |
ip-address } next-hop-local
peer { group-name |
ip-address } reflect-client
policy vpn-target
reflect between-clients
reflector cluster-id
{ cluster-id | ip-address }
extended-community-list-num
ber
1425.
Use the command...
system-view
bgp as-number
Configuring Basic MPLS L3VPN
Remarks
Required
Required
Required
Use one of the commands as
needed.
Optional
Required
By default, only IPv4 routing
information is exchanged
between BGP peers.
Optional
Optional
Optional
By default, no RR or RR client
is configured.
Optional
Enabled by default
Optional
Enabled by default
Optional
Router ID of an RR in the
cluster by default
Optional
"MPLS L2VPN
Remarks
-
-
