To do...
Enter system view
Configure static
routes for a specified
VPN instance
n
Perform this configuration on the PEs. The configuration method on the CEs is
■
the same for configuring ordinary static routes.
For information about static route, refer to
■
Routing" on page
Configuring RIP between PE and CE
A RIP process belongs to only one VPN instance. If you run a RIP process without
binding it to a VPN instance, the process is considered a public network process.
Follow these steps to configure RIP between PE and CE:
To do...
Enter system view
Create a RIP instance between PE
and CE and enter RIP view
n
Perform this configuration on the PEs. Only conventional RIP is required on CEs.
■
After configuring a RIP instance, you must start RIP by using the same method
■
for starting a common RIP process.
For description and detailed configuration about RIP, refer to
■
Configuration" on page
Configuring OSPF between PE and CE
An OSPF process that is bound to a VPN instance does not use the public network
router ID configured in system view. Therefore, you need to specify the router ID
when starting a process or to configure the IP address for at least one interface of
the VPN instance.
An OSPF process belongs to only one VPN instance. If you run an OSPF process
without binding it to a VPN instance, the process is considered a public network
process.
A router ID uniquely identifies an OSPF process on a router. You can specify a
router ID for an OSPF process when starting the process.
Use the command...
system-view
ip route-static dest-address { mask | mask-length }
{ gateway-address | interface-type interface-number
[ gateway-address ] | vpn-instance
d-vpn-instance-name gateway-address }
[ preference preference-value ] [ tag tag-value ]
[ description description-text ]
ip route-static vpn-instance
s-vpn-instance-name&<1-5> dest-address { mask |
mask-length } { gateway-address [ public ] |
interface-type interface-number [ gateway-address ] |
vpn-instance d-vpn-instance-name
gateway-address } [ preference preference-value ]
[ tag tag-value ] [ description description-text ]
817.
Use the command...
system-view
rip [ process-id ] vpn-instance
vpn-instance-name
971.
Configuring Basic MPLS L3VPN
Remarks
-
Required
"Static Routing and Dynamic
Remarks
-
Required
"RIP
