Configuring VPN
Instances

Creating a VPN Instance

Associating a VPN
Instance with an
Interface
Task
"Configuring HoVPN" on page 1495
"Configuring OSPF Sham Link" on page 1496
"Configuring Multi-VPN-instance CE" on page
1497
"Configuring BGP AS Number Substitution" on
page 1498
VPN instances are used to isolate VPN routes from public network routes.
Configuring VPN instances is required in all MPLS L3VPN networking schemes.
In addition, routes of a VPN instance are isolated from those of another. This
feature allows VPN instances to be used in networking schemes other than MPLS
L3VPNs.
All VPN instance configurations are on PEs.
A VPN instance is associated with a site, rather than a VPN. It is a collection of the
VPN membership and routing rules of its associated site.
A VPN instance takes effect only after you configure an RD for it. Before
configuring an RD for a VPN instance, you can configure no parameters for the
instance other than a description.
A VPN instance description is a piece of descriptive information about the VPN
instance. You can use it to keep information such as the relationship of the VPN
instance with a VPN.
Follow these steps to create and configure a VPN instance:
To do...
Enter system view
Create a VPN instance and enter
VPN instance view
Configure an RD for the VPN
instance
Configure a description for the VPN
instance
After creating and configuring a VPN instance, you associate the VPN instance
with the interface for connecting CEs. Any interface supporting MPLS LDP
capability can be associated with a VPN instance. For interfaces supporting MPLS
LDP capability, refer to
Follow these steps to associate a VPN instance with an interface:
Remarks
Optional
Configure it as needed
Optional
Configure it as needed
Optional
Configure it as needed
Optional
Configure it as needed
Use the command...
system-view
ip vpn-instance
vpn-instance-name
route-distinguisher
route-distinguisher
description text
"MPLS Basics Configuration" on page

Configuring VPN Instances

Remarks
-
Required
Required
Optional
1311.
1481
