Docomo Prime SH-06A Instruction Manual page 570

Sending and receiving data
(OBEX ™ communication)
Sending/Receiving FOMA terminal
data to/from a PC
The FOMA terminal has OBEX
communication protocol. Connect the FOMA terminal
to your PC via FOMA USB Cable with Charge
Function 02 (sold separately), and the data
communication (data communication with OBEX
communication) enables sending and receiving
phonebook, owner information from the own number
screen, schedule, sent mail (including SMS), received
mail (including SMS), unsent mail (including SMS),
Area mail, text memos, melodies, My picture, i-motion,
My Documents, bookmark, ToruCa, Decome-Anime
Template, location service client data, and setting
information.
Use the following three types of data communication
with the FOMA terminal.
Send data one item at a time from a PC to a FOMA
terminal (Write 1)
Send data in bulk from a PC to a FOMA terminal
(Write all)
Send data in bulk from a FOMA terminal to a PC
(Read all)
During data communication, the handset will be
outside the service area, and functions such as voice/
Videophone call, i-mode, i-mode mail, or packet
transmission will not be available.
Even after completion of data communication, [A]
(outside the service area) may be displayed for a short
time.
Make sure the FOMA terminal is properly connected to
the PC. If not connected properly, sending and
receiving data may not be possible, or data may be lost.
Check whether there is enough remaining battery
power of the FOMA terminal. If data communication
is performed when the battery level is low or empty,
sending and receiving data may not be possible, or
data may be lost. Performing operations while
charging the FOMA terminal in the desktop holder is
recommended.
Check the PC power supply as well. If not turned on,
sending and receiving data may not be possible, or
data may be lost.
Perform data communication with the FOMA terminal
in stand-by. When movie/i-motion is set as the
stand-by display, stop movie/i-motion playback
before performing data communication.
During communication (voice/Videophone call and
data communication), data cannot be sent or
received. Also, when sending and receiving data,
other data communication cannot be performed.
However, receiving a call, right after data
communication has begun, may be possible. In such
cases, the sending or receiving of data is canceled.
FOMA card phonebook data cannot be sent.
™ function as a data
™
21
Mail with i-appli start up designations can be sent
after attached data has been deleted.
Mail attachment data exceeding 100 KB (including
the message text) are deleted and only message is
sent.
Data such as phonebook entries cannot be sent or
received while All lock is set. Data of locked functions
cannot be received while Function lock is set.
Phonebook data cannot be sent or received when
Keypad dial lock is set.
Depending on data size, data communication may
take some time. In addition, the FOMA terminal may
not be able to receive data due to data size.
When receiving phonebook data, data will be added
from memory number [010] for single entry, or in
accordance with memory number information when
receiving all entries.
When receiving all phonebook entries, Owner
information (excluding first phone number) registered
in Own number will be overwritten.
Phonebook entries are sent in memory number order.
When sending all phonebook entries, Owner
information from own number screen is also sent.
PDF files which exceed 2 MB cannot be sent.
Alternatively, send and receive data (OBEX) with the
following methods.
Ir communication
microSD Card
Devices required for data communication
■
(OBEX ™ communication)
To perform data communication, downloading data
transfer software complied with OBEX
the Internet, and installing this software to your PC is
necessary. Refer to the software manual for
information on operating environment and installation
methods. In addition, installation of the FOMA
communication configuration file (nP. 4 to P. 6) is
necessary beforehand.
A FOMA USB Cable with Charge Function 02 is
required to connect the FOMA terminal to a PC.
The FOMA terminal data communication (OBEX
communication) function complies with IrMC
standard. However, depending on the application,
some data may not be sent or received even when
the other party's terminal complies with IrMC
standard.
iC communication
Bluetooth communication
™ standard from
™
™ 1.1
™ 1.1
