9
Confirm all the settings in the [全般]
(General) tab.
: When two or more modems are connected to the PC
For FOMA USB Cable with Charge Function
02: Make sure that [FOMA SH06A] in [接続
の方法] (Connection method) shows E.
When H appears instead, change to E. For
modems other than [FOMA SH06A], change
E to H.
For Bluetooth connection: Make sure that the
[(in-use Bluetooth-linked standard modem)] or
[(Bluetooth modem provided by a Bluetooth
maker)] in [接続の方法] (Connection method)
shows E. When H appears instead, change
to E. For modems other than the [(in-use
Bluetooth-linked standard modem)] or
[(Bluetooth modem provided by a Bluetooth
maker)], change E to H.
: Confirm that [ダイヤル情報を使う] (Use dialing
rules) shows H. When E appears instead,
change to H.
10
Click the [ネットワーク] (Networking)
tab and confirm all settings.
: In the [この接続は次の項目を使用します]
(Components checked are used by this
connection) field, E should appear only for [イン
ターネットプロトコルバージョン４ (TCP/IPv4)]
(Internet protocol version 4 (TCP/IPv4)). Set [QoS
パケットスケジューラ] (QoS packet scheduler)
according to the instructions of the provider.
11
Click the [オプション] (Option) tab
and click [PPP設定] (PPP setting).
: The PPP setting screen appears.
12
Check all options to show H and
click [OK].
: The option setting screen reappears.
13
Click [OK].
: The host and TCP/IP protocol are set.
: Refer to P. 20 for details on connecting to
dial-up network.
Setting a dial-up network on Windows XP
■
On Windows XP, use ネットワークの接続ウィ
ザード (Network connection wizard) to set both
the host (APN) and TCP/IP protocol.
Example: Using <cid>=3 to connect to mopera U,
the DOCOMO Internet connection
service
Subscription to mopera U requires a charge.
1
Click [スタート] (Start) menu b [す
べてのプログラム] (All programs) b
[アクセサリ] (Accessories) b [通信]
(Communications) b [ネットワーク
接続] (Network connections).
: The network connections screen appears.
2
Click [新しい接続を作成する] (Create
new connection) in the [ネットワー
クタスク] (Network tasks).
: A new connection wizard screen appears.
3
Click [次へ] (Next).
: The screen to select network connection type
appears.
4
Select [インターネットに接続する]
(Dial-up to the Internet) and click [次
へ] (Next).
: A preparation screen appears.
5
Select [接続を手動でセットアップす
る] (Manually set up Internet
connection) and click [次へ] (Next).
: The Internet connection screen appears.
6
Select [ダイヤルアップモデムを使用し
て接続する] (Connect through phone
line and modem) and click [次へ]
(Next).
: A screen to specify the device appears.
