If overwriting of existing data with new data is selected when receiving
all the items of a function, all existing data for that function will be
deleted.
Phonebook
The Group settings of data that is received individually is always set to
[No groups].
When receiving all items, all owner information except own number is
overwritten.
[No Name] appears when data without name is received.
Schedule
Data with no end date/time set will be received with start date/time set
as end date/time.
Mail
May not be able to receive the title completely but a part of it.
Location service client
Phone number cannot be saved to the location service client if the
same phone number has already saved.
Precautions for using Ir communication function
Face the Infrared ports of the receiver's and sender's FOMA terminal
each other and set the distance between them to approximately 20 cm or
less as shown.
362
Infrared port
15°
15°
Infrared port
Approx. 20 cm
or less
While doing Ir communication, leave the Infrared ports facing each other
and do not move.
Ir communication may not function properly directly under fluorescent lights,
near other equipment using infrared signals, or in areas of direct sunlight.
If either of the infrared ports is dirty, Ir communication will become difficult.
Take care not to scratch the ports, and wipe off any dirt with a soft cloth.
When Ir communication could not be performed properly, the
confirmation screen whether to continue appears. Select [Yes] to try
again. Move the FOMA terminals close and try again.
IrSS™ communication performs a transmission without confirming the
response of the receiver side since it uses a simplex communication. For
this reason, the sender side completes the communication normally even
if the receiver side does not.

Sending and receiving data

Terminal security code and authentication password entry are required for
sending or receiving all data items. The authentication password is a
password exclusively for Ir communication. Before starting data transfer, the
sender and receiver must enter the same user-specified four-digit password.
Sending data
<Send Ir data/Send all Ir data>
Example: Phonebook
1
In stand-by, press a.
2
Select a name/C/[Send data]/[Send Ir data].
3
Select the sending method.
;
Select [Send].
;
Select [Send all]/enter the terminal security code/t/enter
the authentication password/t.
: Set the receiving FOMA terminal to receive all data.
4
Select [Yes].
: For Send all, data sending begins if the entered authentication
password matches an authentication password entered by the
receiver.
