1 Earpiece
Listen to the other party's voice.
Listen to Record message/Voice memo.
2 Sub camera
Use to shoot still pictures of yourself.
Use to send images of yourself during a Videophone call.
3 Main display/Touch panel (nP. 28, P. 39)
4 Brightness sensor (nP. 106)
The sensor detects the brightness of the surrounding area and
automatically adjusts the display brightness and turns on/off the
keypad backlight.
Do not cover the sensor area with your hand or a sticker. May
interfere with the sensor.
5 , (;): Optical TOUCH CRUISER (nP. 34)
Slide the finger to perform the same operations as those for w of
Multi-guide key.
6 i (,): i-mode/Operation guidance key
Press to use i-mode (nP. 168).
Press to execute the functions of the operation guidance (nP. 28).
7 m: Mail/Operation guidance key
Press to use mail functions (nP. 134).
Press to execute the functions of the operation guidance (nP. 28).
8 s: Start/Hands-free/Eco key
Press to make or receive a voice call.
Press to use hands-free (nP. 61).
Press to set the Eco mode (Power saver) (nP. 105).
9 1 to 9, 0, *, #: Dial/Text input keys
Press to enter phone numbers or texts.
a $: Multi/Quick search/VeilView key
Press to use Multi Assistant (nP. 377).
Press to use Quick search (nP. 387).
Press to enable/disable the VeilView (nP. 114).
b Mouthpiece/Microphone
Sends out your own voice.
c wt: Multi-guide key
Move the cursor to select an item and execute or set (nP. 28).
d C: Camera/TV/Operation guidance key
Press to activate the camera/1Seg (nP. 216, P. 239).
Press to execute the functions of the operation guidance (nP. 28).
e a: Phonebook/Operation guidance key
Press to use the phonebook (nP. 91).
Press to execute the functions of the operation guidance (nP. 28).
f c (J): i-Channel/Clear key
Press to display the channel list (nP. 201).
Press to return to the previous screen.
Press to delete texts or phone numbers.
g H: Power/End key
Press for 2+ seconds to turn the power on/off (nP. 55).
Use to end the function being activated and return to stand-by display.
h y: MAP/GPS key
Press to activate GPS compatible i-appli (nP. 310).
Press to check your present location. (nP. 309).
i Called/Charging LED
Flashes while receiving a call, etc. (nP. 111).
Illuminates while charging (nP. 50).
j Charger terminal (nP. 53)
This is a terminal for charging with the desktop holder.
k microSD Card slot (nP. 344)
l Strap ring
m Speakers
Emits ring tones, music, etc.
Emits the other party's voice during hands-free operation.
n FOMA antenna
The FOMA antenna is built in. To speak in better conditions, do not
cover the antenna area by hand.
o Sub display (nP. 28)
p External connector terminal
This is a terminal used while charging, connecting the earphone, etc.
Connect to an external device such as AC adapter/DC adapter or
FOMA USB Cable with Charge Function 02 (sold separately)
(nP. 52, P. 354).
q &: Side key
Use to shoot still pictures or moving pictures (nP. 216, P. 220).
Press with the FOMA terminal closed to display the clock on the sub
display.
Press for 1+ seconds with the FOMA terminal closed to turn on/off
Picture Light.
r 1Seg antenna (nP. 237)
Use to receive 1Seg.
Continued on next page
25
