Set network transmission
without using DOCOMO

Connection Manager

Setting communications for packet
transmission and 64K data
communication
This section describes how to set up packet
transmission and 64K data communication
without using DOCOMO Connection Manager.
To make the settings, communication software for
entering AT commands are required. "Hyper
terminal", which is included as standard with
Windows, is used here.
The flow for setting up with use of AT commands is as
follows.
To use 64K data communication, there is no host
(APN) setting.
Windows Vista is not compatible with "Hyper terminal".
Use Windows Vista compatible software to set up
communications (follow the instructions for the
software).
Start up communication software that supports AT
commands (steps 2 to 5)
Set the host Set the Send/
(APN) Not send caller
(nsteps 6 and ID
7 on P. 12) (nP. 13)
End communication software (nstep 7 on P. 12)
Install the FOMA communication configuration file
before making settings for packet transmission and
64K data communication (nP. 4).
AT commands are commands for controlling the
modem. The FOMA terminal is compliant with AT
commands and also supports some extended
commands, as well as some unique AT commands.
Making host (APN) settings is not necessary when
using mopera U or mopera, the DOCOMO Internet
connection service, since it is set as the default.
Set Notify caller ID as necessary (When using
mopera U or mopera, set [Send]). The default setting
is [Not send].
Set other settings as necessary. Use is possible with
the default settings.
Set the host (APN) for using packet transmission.
Register up to ten numbers. Hosts are managed
using cid numbers from 1 to 10 (nP. 12).
The default setting for the first cid is
mopera.ne.jp, the APN used to connect to
mopera. The default setting for the third cid is
mopera.net, the APN used to connect to mopera
U. Save hosts (APN) to cid2 or 4 to 10.
Example: When using FOMA USB Cable with
2
Set the Dial-up
Network
(nP. 13)
3
11
Setting host (APN)
The registered cid is the connection number set in the
dial-up connection settings.
A separate host (APN) is required to be set for USB
connection and Bluetooth connection.
If USB connection and Bluetooth connection are
switched during packet transmission, the host (APN) is
required to be set again.
Contact the Internet service provider or network
administrator for hosts (APNs) other than mopera U or
mopera.
Charge Function 02 (sold separately)
on Windows XP
The screens are different for Windows 2000.
1
Connect the FOMA terminal to your
PC via FOMA USB Cable with
Charge Function 02.
Select [スタート] (Start) menu b [す
べてのプログラム] (All programs) b
[アクセサリ] (Accessories) b [通信]
(Communications) b [ハイパーター
ミナル] (Hyper terminal).
: Hyper terminal starts up.
For Windows 2000
: Select [スタート] (Start) menu b [プログラム]
(Programs) b [アクセサリ] (Accessories) b
[通信] (Communications) b [ハイパーターミナ
ル] (Hyper terminal).
Enter a name (such as a host name)
in the [名前] (Name) field and click
[OK].
: The advanced settings screen for phone
number appears.
