ADI_EBIU_ASYNCH_BANK_ENABLE

This enumeration specifies which banks are being enabled. It corresponds
to the bits in the asynchronous memory global control register.
AMBEN
ADI_EBIU_ASYNCH_DISBALE_ALL
ADI_EBIU_ASYNCH_BANK0
ADI_EBIU_ASYNCH_BANK0_1
ADI_EBIU_ASYNCH_BANK0_1_2
ADI_EBIU_ASYNCH_BANK0_1_2_3

ADI_EBIU_ASYNCH_CLKOUT

This enumeration specifies whether
access. It corresponds to the
bal control register.
ADI_EBIU_ASYNCH_CLKOUT_DISABLE
ADI_EBIU_ASYNCH_CLKOUT_ENABLE

ADI_EBIU_ASYNCH_BANK_DATA_PATH

This enumeration is for the ADSP-BF561 only. It specifies whether 16-bit
packing is enabled on the asynchronous memory bus. It corresponds to
the bits in the asynchronous memory global control register, where
BXPEN
is the bank number.
X
ADI_EBIU_ASYNCH_BANK_DATA_PATH_32
ADI_EBIU_ASYNCH_BANK_DATA_PATH_16
VisualDSP++ 5.0 Device Drivers and System
Services Manual for Blackfin Processors
External Bus Interface Unit Module
Disables all banks.
Enables bank 0.
Enables banks 0 and 1.
Enables banks 0, 1, and 2.
Enables all banks.
is enabled for external memory
CLKOUT
bits in the asynchronous memory glo-
AMCKEN
is disabled.
CLKOUT
is enabled.
CLKOUT
16-bit packing in NOT enabled.
16-bit packing is enabled.
4-45
