ADI_EBIU_SDRAM_BANK_SIZE

This enumeration specifies the SDRAM external bank size. This enumera-
tion corresponds to the
ADI_EBIU_SDRAM_BANK_16MB
ADI_EBIU_SDRAM_BANK_32MB
ADI_EBIU_SDRAM_BANK_64MB
ADI_EBIU_SDRAM_BANK_128MB
The default value is specified by the following macro:
#define ADI_EBIU_SDRAM_BANK_SIZE_DEFAULT
ADI_EBIU_SDRAM_BANK_32MB

ADI_EBIU_SDRAM_BANK_COL_WIDTH

This enumeration specifies the SDRAM external bank column address
width and corresponds to the
ADI_EBIU_SDRAM_BANK_COL_8BIT
ADI_EBIU_SDRAM_BANK_COL_9BIT
ADI_EBIU_SDRAM_BANK_COL_10BIT
ADI_EBIU_SDRAM_BANK_COL_11BIT
The default value is specified by the following macro:
#define ADI_EBIU_SDRAM_BANK_COL_WIDTH_DEFAULT
ADI_EBIU_SDRAM_BANK_COL_9BIT

ADI_EBIU_SDRAM_MODULE_TYPE

This enumeration specifies an SDRAM module type when the command
ADI_EBIU_CMD_SET_SDRAM_MODULE
troller. The enumerator values contain relevant module information such
VisualDSP++ 5.0 Device Drivers and System
Services Manual for Blackfin Processors
External Bus Interface Unit Module
bits in the
EBSZ EBIU_SDBCTL
16MB external SDRAM
32MB external SDRAM
6 4MB external SDRAM
128MB external SDRAM
bits in the
EBCAW
8-bit external bank column address width
9-bit external bank column address width
10-bit external bank column address width
11-bit external bank column address width
is used to initialize the SDRAM con-
register.
register.
EBIU_SDBCTL
4-39
