Table 3-8. PM Module Macros (Cont'd)
Macro
ADI_PWR_VR_FREQ_DEFAULT
ADI_PWR_VR_FREQ_MIN
ADI_PWR_VR_FREQ_MAX
ADI_PWR_VR_GAIN_DEFAULT
ADI_PWR_VR_GAIN_MIN
ADI_PWR_VR_GAIN_MAX
ADI_PWR_PROC_BF533SKBCZ600
ADI_PWR_PROC_BF533SBBZ500
ADI_PWR_PROC_BF532SBBC400
ADI_PWR_PROC_BF532SBST400
ADI_PWR_PROC_BF532SBBZ400
ADI_PWR_PROC_BF531SBBC400
ADI_PWR_PROC_BF531SBST400
ADI_PWR_PROC_BF531SBSTZ400
ADI_PWR_PROC_BF531SBBZ400
VisualDSP++ 5.0 Device Drivers and System
Services Manual for Blackfin Processors
Power Management Module
Explanation
Default/reset switching frequency value,
ADI_PWR_FREQ_1MHZ
Minimum switching frequency value,
ADI_PWR_FREQ_POWERDOWN
Maximum switching frequency value,
ADI_PWR_FREQ_1MHZ
Default/reset voltage regulator gain value,
ADI_PWR_GAIN_20
Minimum voltage regulator gain value,
ADI_PWR_GAIN_5
Default/reset voltage regulator gain value,
ADI_PWR_GAIN_20
Equivalent processor type to
ADI_PWR_PROC_BF533SKBC600
Equivalent processor type to
ADI_PWR_PROC_BF533SBBC500
Equivalent processor type to
ADI_PWR_PROC_BF531_OR_BF532
Equivalent processor type to
ADI_PWR_PROC_BF531_OR_BF532
Equivalent processor type to
ADI_PWR_PROC_BF531_OR_BF532
Equivalent processor type to
ADI_PWR_PROC_BF531_OR_BF532
Equivalent processor type to
ADI_PWR_PROC_BF531_OR_BF532
Equivalent processor type to
ADI_PWR_PROC_BF531_OR_BF532
Equivalent processor type to
ADI_PWR_PROC_BF531_OR_BF532
.
